Dongfeng 3500L Road Sweeper Truck Small 4 X 2 500KG 66KW 90HP
Dongfeng 3500L Road Sweeper Truck Small 4 X 2 500KG 66KW 90HP
Dongfeng 3500L Road Sweeper Truck Small 4 X 2 500KG 66KW 90HP
Dongfeng 3500L Road Sweeper Truck Small 4 X 2 500KG 66KW 90HP
Dongfeng 3500L Road Sweeper Truck Small 4 X 2 500KG 66KW 90HP
Dongfeng 3500L Road Sweeper Truck Small 4 X 2 500KG 66KW 90HP
Specifications
Brand Name :
SUNY
Model Number :
DFA1041SJ35D6
Certification :
CCC, ASME, BV, SGS, etc
Place of Origin :
China
MOQ :
1 unit
Price :
USD 30000-35000 / Set
Supply Ability :
50 sets per month
Delivery Time :
25 days after receiving deposits
Packaging Details :
bulk, ro-ro, container
Type :
4 X 2 Dust Sunction Truck
G. V. W. ( kg ) :
4495
Wheelbase (mm) :
3300
Tire & Quantity :
7.00-16 & 6+1
Engine :
YC4FA90-40
Maximum Power :
66kw/90hp
Dustbin Capacity (L) :
3500
Loading Capacity (kg) :
500
Description

Dongfeng 3500L Road Sweeper Truck Small 4 X 2 500KG 66KW 90HP

Product Description:

Research on particle characteristics on urban road surface reveals that the particle size distribution is not consistent with the pollution distribution, and pollutant are typically associated with the smaller size particles. Since pollutants are the main function for street vacuum sweeper, a more accurate method of evaluating the particle removal performance of street vacuum sweeper is using grade efficiency.

1. Product Parameter

Products Technical Specification

Type

Dust suction truck

Vehicle Description

Overall dimensions(mm)

5995×1990×2590

G.V.W (kg)

4495

Curb weight(kg)

3815

Max speed (Km/h)

95

Engine Description

Engine model

YC4FA90-40

Engine Type

4 cylinders, straight in-line, exhaust turbo charging system to improve engine power

Maximum power

66kw/90hp

Displacement (lit)

2982

Chassis Description

Chassis model

DFA1041SJ35D6

Wheel base(mm)

3300

F/R track base(mm)

1506/1466

F/R overhang(mm)

1032/1663

Approach/Departure angle(°)

19/13

Spring plate

6/6+5

Front / rear axle (T)

1.8/2.7

Driving Type

4×2,left hand drive

Tyre&Quantity

7.00-16&6+1

Up-parts Description

Max sweeping width(mm)

2800

Sweep efficient

More than 96%

Sweep speed(Km/h)

5-20

Hydraulic pressure(Mpa)

12

Suction cap ground clearance in working(mm)

5-10

Dustbin capacity(m3)

4.5

Max operating capacity

45000 square meters per hour

The biggest diameter of suction granularity(mm)

Less than 50

Dongfeng 3500L Road Sweeper Truck Small 4 X 2 500KG 66KW 90HPDongfeng 3500L Road Sweeper Truck Small 4 X 2 500KG 66KW 90HP
