4x2 Dongfeng Sanitation Truck , 5000L 2000KG Street Cleaner Truck
4x2 Dongfeng Sanitation Truck , 5000L 2000KG Street Cleaner Truck
4x2 Dongfeng Sanitation Truck , 5000L 2000KG Street Cleaner Truck
4x2 Dongfeng Sanitation Truck , 5000L 2000KG Street Cleaner Truck
Specifications
Brand Name :
SUNY
Model Number :
DFA1070SJ35D6
Certification :
CCC, ASME, BV, SGS, etc
Place of Origin :
China
MOQ :
1 unit
Price :
USD 30000-35000 / Set
Supply Ability :
50 sets per month
Delivery Time :
25 days after receiving deposits
Packaging Details :
bulk, ro-ro, container
Type :
4 X 2 Dust Sunction Truck
G. V. W. ( kg ) :
7300
Wheelbase (mm) :
3300
Tire & Quantity :
7.00-16 & 6+1
Engine :
CY4102-CE4F
Maximum Power :
73kw/100hp
Dustbin Capacity (L) :
5000
Loading Capacity (kg) :
2000
Description

4x2 Dongfeng Sanitation Truck , 5000L 2000KG Street Cleaner Truck

Product Description:

With the rapid development of the computer technology, the computational fluid dynamics has been successfully adopted to study various industrial pneumatic conveyjing processes. Although many works have studies the particle removal performance by experiments over the past decades, few works considered the particle removal performance of pickup head using.The study showed that the perfomance of street sweeping was improved significantly by changing the structure of pickup head, and the numerical simulation proved that the CFD was an effective tool to calculate the flow field characteristics of pickup head.

1. Product Parameter

Products Technical Specification

Type

Dust suction truck

Vehicle Description

Overall dimensions(mm)

6150×2330×2550

G.V.W (kg)

7300

Curb weight(kg)

5170

Max speed (Km/h)

105

Engine Description

Engine model

CY4102-CE4F

Engine Type

4 cylinders, straight in-line, exhaust turbo charging system to improve engine power

Maximum power

73kw/100hp

Displacement (lit)

3856

Chassis Description

Chassis model

DFA1070SJ35D6

Wheel base(mm)

3300

F/R track base(mm)

1506/1466

F/R overhang(mm)

1032/1818

Approach/Departure angle(°)

19/11

Spring plate

8/9+5

Front / rear axle (T)

3/4.3

Driving Type

4×2,left hand drive

Tyre&Quantity

7.00-16&6+1

Up-parts Description

Max sweeping width(mm)

2800

Sweep efficient

More than 96%

Sweep speed(Km/h)

5-20

Hydraulic pressure(Mpa)

12

Suction cap ground clearance in working(mm)

5-10

Dustbin capacity(m3)

5

Max operating capacity

45000 square meters per hour

The biggest diameter of suction granularity(mm)

Less than 50
