Changan 1cbm / 2cbm 4x2 Waste Trucks 2 Axles 53HP With Diesel Arm Hook
Changan 1cbm / 2cbm 4x2 Waste Trucks 2 Axles 53HP With Diesel Arm Hook
Changan 1cbm / 2cbm 4x2 Waste Trucks 2 Axles 53HP With Diesel Arm Hook
Changan 1cbm / 2cbm 4x2 Waste Trucks 2 Axles 53HP With Diesel Arm Hook
Changan 1cbm / 2cbm 4x2 Waste Trucks 2 Axles 53HP With Diesel Arm Hook
Changan 1cbm / 2cbm 4x2 Waste Trucks 2 Axles 53HP With Diesel Arm Hook
Changan 1cbm / 2cbm 4x2 Waste Trucks 2 Axles 53HP With Diesel Arm Hook
Changan 1cbm / 2cbm 4x2 Waste Trucks 2 Axles 53HP With Diesel Arm Hook
Specifications
Brand Name :
SUNY
Model Number :
SY1403GBS
Certification :
CCC, ASME, BV, SGS, etc
Place of Origin :
China
MOQ :
1 unit
Price :
USD 8,000~ 15,000 FOB Shanghai
Supply Ability :
1000 units per year
Packaging Details :
Ro-ro shipping / Bulk cargo shipping / Container shipping / SKD / CKD / etc
Garbage Container capacity :
1m3 2m3
Truck chassis wheelbase :
2500 mm
Whole truck dimension :
4150*1530*2280 mm
Truck engine :
53hp
Engine emission standard :
euro 2, euro 3, euro 4, euro 5
Garbage Con :
side 3mm, bottom 4mm
Garbage Container shape :
aqusre shape, boat shap, bucket shape
Garbage Containers :
one truck to many garbage containers
Description

Changan 1cbm / 2cbm 4x2 Waste Trucks 2 Axles 53HP With Diesel Arm Hook



Description:

The arm hook garbage truck is widely used in sanitation, industrial enterprises and residential area. The truck has several garbage tanks to avoid pollution during transporting process. The modified part can be separated from chassis, so it is easy to maintain and the mobility & readability of the truck are kept.


Competitive Advantage:

1- strict quality control
2- competitive price
3- best service
4- powful R & D capabilities



Specifications:

Vehicle
description

Overall dimensions(mm)

4150*1530*2280

GVW (kg)

1800

Mass in working order(kg)

1200

Rated loading capacity(kg)

470

chassis
parameters

Chassis mod

SC1022DB4

Fact cubage(L)

500

Approach/Departure angle(°)

58/29

F/R overhang(mm)

480/1170

Wheel base(mm)

2500

F/R track base(mm)

1280/1290

Traction system

4*2

Number of axles

2

F/R axle-load(Kg)

860/940

Spring plate

-/5

Braking system

Air braking

Tire specification

165/70R13LT

Number of tires

4+1

Electric system

24v

Allowable passengers in cab

2

Air-conditioner

optional





Engine

Engine model

JL66Q4

Type of fuel

Diesel

Exhaust(ml)

1012

Rated Power(kw)

39

Horse power

53

Operation control system

Steering wheel

transmission

-speed

Max speed(km/h)

95

Manufacturer

Chongqing Chang’an Automobile Co., Ltd

Emission standard

EURO 3

Up-parts Description

Remarks

Compartment volume (M3):3CBM Cycle time (S):≤28 Excretion of garbage time (S):≤30 Arm hook lifting capacity:3tons Cargo body description:Equipped with material of carbon steel, side 5mm thickness;bottom 6mm thickness. Equipped with hermetic dustbin, hydraulic system and operating system.
Operation control system:Manual + electric Optional:Pneumatic control in the cab

Modified Description

1. Adopt interlocks of chain and hydrocylinder, realising garbage bucket lifting and overturning.
2. Taking garbage from the bucket to container and disposable dumping.
3. Sealed and self-chambering and self-discharging and hydraulic operating.

Composition

Basic composition: chassis, sealed garbage box, interlocks of chain and hydrocylinder, hydraulic system,operating sysytem, hydraulic pump.

Purpose

Mainly used in places of a lot of garbage, like sanitation, factories, housing estate also be used in transporting dust, sand, stone, mine, coal and many other materials.

Production cycle

15-20 days
