Dongfeng 4 - 5m3 Diesel Arm Hook Garbage Trucks , 4x2 Drive Refuse Truck
Dongfeng 4 - 5m3 Diesel Arm Hook Garbage Trucks , 4x2 Drive Refuse Truck
Dongfeng 4 - 5m3 Diesel Arm Hook Garbage Trucks , 4x2 Drive Refuse Truck
Dongfeng 4 - 5m3 Diesel Arm Hook Garbage Trucks , 4x2 Drive Refuse Truck
Dongfeng 4 - 5m3 Diesel Arm Hook Garbage Trucks , 4x2 Drive Refuse Truck
Dongfeng 4 - 5m3 Diesel Arm Hook Garbage Trucks , 4x2 Drive Refuse Truck
Dongfeng 4 - 5m3 Diesel Arm Hook Garbage Trucks , 4x2 Drive Refuse Truck
Dongfeng 4 - 5m3 Diesel Arm Hook Garbage Trucks , 4x2 Drive Refuse Truck
Specifications
Brand Name :
SUNY
Model Number :
SY1401GBS
Certification :
CCC, ASME, BV, SGS, etc
Place of Origin :
China
MOQ :
1 unit
Price :
USD 12,000~ 25,000 FOB Shanghai
Supply Ability :
1000 units per year
Packaging Details :
Ro-ro shipping / Bulk cargo shipping / Container shipping / SKD / CKD / etc
Garbage Container capacity :
4M3 5M3 6M3
Garbage Container material :
side 3mm, bottom 4mm
Garbage Container shape :
aqusre shape, boat shap, bucket shape
Garbage Containers :
one truck to many garbage containers
Engine emission standard :
euro 2, euro 3, euro 4, euro 5
Whole truck dimension :
6150x1950x2850 mm
Truck chassis wheelbase :
3300mm
Description

Dongfeng 4 - 5m3 Diesel Arm Hook Garbage Trucks , 4x2 Drive Refuse Truck

Description:

The garbage truck is widely used in sanitation & municipal, industrial enterprises and residential area. The truck has several garbage tanks to avoid pollution during transporting process. The modified part can be separated from chassis, so it is easy to maintain and the mobility & readability of the truck are kept.
If you have special demand of garbage truck, please contact with us. We may design and modify it for you. We also can add power steering and A/C for you.

Competitive Advantage:

1- powful R & D capabilities ------ we can design and produce the truck according to different trash cans of different countries so that it can be fit for the different countries’ demand.

2- strict quality control ---- stable quality for each truck

3- competitive price ----- based on same product, our price is most competitive

4- best service ----- we cherish each customer and opportunity.

Specifications:

Chassis name

EQ1060

Capacity of body

4-5cbm

Specification of vehicle

Outside dimension(mm):

6150x1950x2850

Total weight (kg):

4495

Loading weight (kg):

685

Net weight(kg):

3680

Approach / departure angle(mm):

19/13

Front / rear suspension(mm):

1032/1818

Fuel type:

Diesel

Max. speed(km/h):

95

Engine specs

Model :

CY4102-C3F/YC4F90-30/YN30CR

Manufacturer :

Dongfeng chaochai motor co., ltd.
Guangxi yuchai
yunnei

Displacement (ml):

3856/2659/2977

Power (kw):

70/66/76

Chassis specs

Driving type:

4×2

Wheelbase(mm):

3300

Tread(front/rear):

1506/1442

Displacement standard:

GB17691-2005 Euro 3,GB3847-2005

Front / rear axle(T):

1.8T/3T

Gear box:

Five forwards, one revere, mechanical

Brake system:

Pneumatic

Cab:

Single cab

Spring file(front/rear):

8/9+5

Tyre:

7.00-16

Air condition:

Optional

Special function

Working pressure of hydraulic:

16MPa

Turn radius of loading arm:

2400mm

Flux of hydraulic system:

50L/min

Max. Boom angle:

145

Lifting the bucket time:

30s

Unloading bucket time:

50s

Dongfeng 4 - 5m3 Diesel Arm Hook Garbage Trucks , 4x2 Drive Refuse Truck

Dongfeng 4 - 5m3 Diesel Arm Hook Garbage Trucks , 4x2 Drive Refuse Truck
