HV Three Phase Hybrid Inverter For On Grid And Off Grid Operations
HV Three Phase Hybrid Inverter For On Grid And Off Grid Operations
Specifications
Brand Name :
GK
Model Number :
GK HTHI
Certification :
IEC 61727 IEC 62116 CEI 0-21 EN50549-1 G99 G98
Place of Origin :
China
MOQ :
5 units
Price :
consult prices online
Payment Terms :
T/T
Packaging Details :
consult online
Max. Efficiency :
97.60%
PV Input Power :
65,000W
Max. Charging/Discharging Current :
100A
Battery Voltage Range :
160~800V (Lithium-ion)
Rated AC Output Power :
50,000W
Ingress Protection :
IP65
Description

HV Three-phase Hybrid Inverter The Ideal Solution for On-grid and Off-grid Operations

Product Description:

The HV Three-phase Hybrid Inverter is an advanced energy management solution designed to integrate both AC and DC coupling, offering superior flexibility for existing solar system retrofits. It features high efficiency with a maximum efficiency of 97.60% and an MPPT efficiency exceeding 99%. Equipped with robust protection systems such as DC polarity reverse connection, AC output overcurrent, and AC output overvoltage protection, this inverter guarantees system safety and long-term stability. With a colorful touch LCD and IP65 protection degree, the system is built for durability and ease of use in various environments.

Battery Input Data
BatteryType Lithium-ion
Bottery Voltoge Range 160-800V
Max Charging Current 50+50A
Max.Discharging Cument 50+50A
Charging Strategy for Li-ion Battery Self-adoption to BMS
Number of battery input 2
PV String Input Data
Max.DC Input Power 38870W 39000W 45500W 52000W 65000w
Max.DC Input Voltage 1000V
Start-up Voltage 180V
MPPT Voltoge Range 150-850V
Roted DC Input Voltoge 600V
Max.Operating PV Input Current 36+36+36A 36+36+36+36A
Max.Input Short-Circuit Current 55+55+55A 55+55+55+55A
No.of MPP Trackers/ 3/2+2+2
No.of Stings per MPP Tracker		 4/2+2+2+2
AC Input/Output Data
Rated AC Input/Output Active Power 29900W 30000W 35000W 40000W 50000W
Max.AC Input/Output Apparent Power 29900W 33000W 38500W 44000W 55000W
Rated AC Input/Output Current 45.4/43.4A 45.5/43.5A 53.1/50.8A 60.7/58A 75.8/72.5A
Max.AC Input/Output Current 45.4/43.4A 50/47.9A 58.4/55.8A 66.7/63.8A 83.4/79.9A
Max.Three-phaseUhbalancdOutputCurert 60A 60A 60A 70A 83.3A
Max.Continuous ACPossthrough(gid toload) 200A
Peak Power (off grid) 1.5 time of rated power,10S
Power Foctor Adjustment Range 0.8 leading to 0.8 lagging
Rated Input/Output Voltage/Range 220/380V,230/400V 0.85Un-1.1Un
Rated Input/Output Grid Frequency/Range 50/45-55,60/55-65
Grid Connection Fom 3L+N+PE
Total Current Harmonic Distortion THD <3%(of nominal power)
DCComponent of Grid <0.5%In
Protection
DCPolarity Reverse Connection Protection,ACOutput Overcurrent Protection,ACOutput Overvoltoge
Protection,AC Output Short CrauitProtection,ThemalProtection DC Terminal hsulation Impedarce
Monitorng,DCComponent Monitoring,Ground Foult Current Monitoring,Power Network Monitoring,
IslandProtection Monitoring,Earth Foult Detection,DCInput Switch Overvoltoge LoodDrop Protection,
ResidualCurent (ROD)Detection,Surge protection level
DC Type ll/AC Type Il
Interface
Communication Interface WIFI,RS485,CAN
General Dota
Operating Temperature Range(℃) -40-60℃,>45℃ derating
Permissible Ambient Humidity 0~100%
Permissible Altitude 2000m
Noise <65 dB(A)
Ingress Protection(IP)Rating IP65
Inverter Topology Non-lsolated
Over Voltoge Category OVCI(DC),OVCⅢ(AC)
Size(W*H*D) 527*894*294mm/20.7*35.2*11.6 in (Excluding Connectors and Brackets)
Weight 80kg/176 Ibs
Type ofCooling Intelligent Air Cooling
Warranty 5 Yeos 00 Years Optional)
the Waranty Period Depends the FnollnstolotionSite of ihverter,MoreInfo Please Refe to Waranty Policy
Grid Regulation EC61727,IEC62116,CEI0-21,EN50549,NRS097,RD 140,UNE 217002,OVERichtirnie R25,G99,VDE-ARN4105
Safety/EMC Standard IECEN 61000-6-1213/4,ECEN621091,ECEN62109-2

Application:

The HV Three-phase Hybrid Inverter is ideal for large residential, commercial, and industrial installations. It supports on-grid and off-grid operations, making it suitable for a wide range of applications where energy storage and management are critical. The system can manage up to 10 units in parallel for increased capacity and supports storing energy from diesel generators, providing a comprehensive power backup solution.

Shipping Methods

Supports global air and sea shipping.
