IP65 Hybrid Inverter For Outdoor Installation In Solar Energy Systems
IP65 Hybrid Inverter For Outdoor Installation In Solar Energy Systems
Specifications
Brand Name :
GFS
Certification :
CE
Place of Origin :
China
MOQ :
10 units
Price :
consult prices online
Payment Terms :
T/T
Packaging Details :
consult prices online
Rated Power :
3000W to 10000W
Efficiency :
Up to 98% (Europe Efficiency: 96-97%)
Input Voltage Range :
100V-850V DC
Cooling Method :
Natural or intelligent air cooling
Protection Degree :
IP65
Communication Interfaces :
RS232, RS485, GPRS (Optional)
Description

Hybrid Inverter with IP65 Rating for Outdoor Installation in Solar Energy Systems

IP65 Hybrid Inverter For Outdoor Installation In Solar Energy Systems

Product Description:

The hybrid inverter is designed to deliver maximum efficiency of up to 98% while supporting wide input voltage ranges with high-efficiency MPPT technology. This product is designed for solar PV systems, allowing multiple inverters to be connected in parallel to increase output capacity. It features strong IP65 protection, making it suitable for outdoor installation, and is small and lightweight for ease of installation. The inverter is compatible with RS232, RS485, and GPRS monitoring options, offering flexible communication modes. This makes it ideal for home, commercial, and industrial solar energy applications.

DCINPUT
Max.DC input power 3200W 5400W 5500W 10500W
Max.DCinput voltage 500VDC 500VDC 850VDC 850VDC
Max.DC input current 13A 26A 15A 30A
Power off/on voltage 100V/200VDC 100V/200VDC 200V/300VDC 200V/300VDC
OUTPUT(AC)
Rated Power 3000W 5000W 5000W 10000W
Rated voltage 110V/230VAC 110V/230VAC 380V±40V 380V±40V
Frequency 50Hz/60Hz 50Hz/60Hz 50Hz/60Hz 50Hz/60Hz
Phase number Single Phase L+N+PE Single Phase L+N+PE Three Phase L+N+PE Three Phase L+N+PE
Power Factor 1 1 0.99 0.99
Max Current 13.6A 23A 7.5A 15A
CurrentTHD(AT Rated Power) <3.5% <3.5% <3.5% <3.5%
Max Efficiency 97.3% 97.6% 98% 98%
Europe Efficiency 96% 97.1% 97% 97%
STRUCTURE
Protection Degree IP65 IP65 IP65 IP65
Cooling Method Natural Cooling Natural Cooling Interlligent Air Cooling Interlligent Air Cooling
Display LCD LCD LCD LCD

Isolation type Non-isolated Non-isolated Non-isolated Non-isolated
Topology No Transformer NoTransformer No Transformer No Transformer
InputTermina MC4 MC4 MC4 MC4
Output Termina Connector terminals Connector terminals Connector terminals Connector terminals
Data interfaces RS232/RS485
WiFI/GPRS(Optional)		 RS232/RS485
WiFi/GPRS(Optional)		 RS232/RS485
WiFi/GPRS(Optional)		 RS232/RS485
WiFi/GPRS(Optional)
GENERAL PARAMETERS
Noise <50dB <50dB <50dB <50dB
Night power Consumption <0W <0W <0W <0W
Operation temperature Range -10℃-60℃ -10℃~60℃ -10℃~60℃ -10℃~60℃
Storage temperature -15℃~60℃ -15℃~60℃ -15℃~60℃ -15℃~60℃
Relatve humidity 0~100% 0~100% 0~100% 0~100%
Altitude ≤2000m ≤2000m ≤2000m ≤2000m
Size(W*H*D) 335*365*150mm 405*415*190mm 405*560*260mm 420*610*260mm
Wei ght 14kg 22kg 38kg 42kg
Note:can be customized according to customer requirements

Application:

This hybrid inverter is ideal for a variety of solar energy applications, including residential, commercial, and industrial settings. Its ability to operate multiple inverters in parallel and support remote monitoring makes it suitable for both small and large-scale solar power systems. The advanced protection functions, including anti-island, input/output voltage regulation, and grid monitoring, ensure the safety and stability of the energy supply. It is particularly effective in locations with variable grid conditions or where solar energy is the primary energy source.

Shipping Methods

Supports global air and sea shipping.
