33-50W High Efficiency Central Inverters With Intelligent String Monitoring
33-50W High Efficiency Central Inverters With Intelligent String Monitoring
Specifications
Brand Name :
LS
Model Number :
LS2IPVI
Certification :
NB/T 32004-2018 IEC61727 NB/T 32004-2018 EC 62109-1/2
Place of Origin :
China
MOQ :
66 sets
Price :
consult prices online
Payment Terms :
T/T
Packaging Details :
consult online
Rated Output Power :
33kW - 50kW
Max DC Input Power :
39,600W - 60,000W
MPPT Voltage Range :
200 - 1000Vdc
Nominal Output Voltage :
400V
Max. Efficiency :
98.7%
THD (Total Harmonic Distortion) :
<2%
Max. Operating Altitude :
4000m
Dimensions :
610mm x 564mm x 218mm
Description

33-50W High-Efficiency Central Inverter with Intelligent String Monitoring

Product Description:

The LSBH (33~50) KTL3-OC is a high-efficiency central inverter designed to support large-scale solar power systems. With a maximum efficiency of 98.7% and support for wide voltage input, this model is ideal for both commercial and utility-scale solar installations. Its fan cooling technology ensures optimal thermal management even in demanding environments. This model is designed with up to 3 to 4 MPPTs (Maximum Power Point Tracking) for improved energy harvest from PV systems with different string orientations or partial shading conditions.

The inverter also supports intelligent features like GPRS/WiFi communication for simplified installation and reduced wiring costs. It provides intelligent string monitoring, supports RS485 communication, and offers AFCI protection, reducing the risk of fire. Additionally, its night-time PID recovery function helps increase overall system yield by maintaining high energy efficiency.

Product Model LSBH33KTL3-0C1 LSBH36KTL3-0c1 LSBH40KTL3-0c1 LSBH50KTL3-0C1
Input Max.DC Input Power 39600W 43200W 48000W 60000W
Max.DC InputVotage 1100V
Max.DCInputCurent 36A/36A/20A 36A/36A/20A/20A
MPPT Votage Range 200~1000Vdc
Recommended Working Voltage 650V
MPPT Number 3 4
Max hput Strings per MPPT 02/2/2 2/2/2/2
Output Rated Output Power 33000W 36000W 40000W 50000W
Max.AC Power 36.3kVA 39.6kVA 44kVA 55kVA
Max.OutputCurrent 53A 56A 65A 80A
Rated Power Gnd Voltage 400V
PowerGnd Votage Range 310-480Vao
Bated Power Gnd Frequency 50Hz/60Hz
Grid Frequency Range 45-55Hz/55-65Hz
THD <2%(under rated power)
Power Factor >0.99 (under rated power)/Adjustable range0.8(leading)-0.8(lagging)
DC Component <0.5%(under rated power)

System
Data		 Max.Efficiency 98.6% 98.6% 98.6% 98.7%
Euro,officiency 98.1% 98.1% 98.2% 98.2%
Humidity 0-100%,no condensation
Cooing Fan
Ambient Temperature Range -25~+60℃
Consumption During Night <1W
Altitude 4000m
Display LED/LCD(optional)
Communication Interface RS485/GPRS/Wifi (optional)
Mechanica
Data		 Size 610x564x218mm
Weight 37kg 39kg
Protection Level IP66
Conforming
Standards		 Standards for Grd Connection NB/T 32004-2018;IEC61727
Safety Standard NB/T 32004-2018;EC 62109-1/2
EMC IEC61000-6-2/4
Remarks:Speciications are subject to change without notice;Special voltage and power requirements can be customized designed

Application:

The LSBH (33~50) KTL3-OC is ideally suited for large commercial solar installations and utility-scale power plants. It is perfect for scenarios requiring high power output and robust grid support while optimizing energy efficiency. The inverter’s durable design and IP66 protection make it suitable for harsh environmental conditions, supporting energy generation across a wide range of temperatures and altitudes.

Shipping Methods:

Supports global air and sea shipping.
