13kWh 15kWh DB Lithium Battery Storage High Capacity Portable Energy Solutions For High Demands
13kWh 15kWh DB Lithium Battery Storage High Capacity Portable Energy Solutions For High Demands
Specifications
Brand Name :
DS
Model Number :
DS-DBL
Certification :
IEC62619/EN61000-6-1/ EN61000-3/RoHS/UN38.3
Place of Origin :
China
MOQ :
6 set
Price :
consult prices online
Payment Terms :
T/T
Packaging Details :
600*425*468/560*330*950/560*330*910/560*330*950
Cell Chemistry :
All models: LFP
Cell Configuration :
16S1P/8S1P
Nominal Energy :
12288 Wh/14336 Wh/15360 Wh/16077 Wh
Nominal Voltage :
All models: 51.2 V
Working Voltage Range :
DDDKYG51240, DDDKYG51280: 43.2~57.6 VDC/DDDLSG51300, DDDLSG51314: 21.6~28.8 VDC
Max. Charge/Discharge Current :
DDDKYG51240: 200 A/DDDKYG51280: 280 A/DDDLSG51300: 280 A/DDDLSG51314: 100 A
Cycle Life :
All models: 6000 cycles
IP Rating :
All models: IP21
Description

13kWh 15kWh DB Lithium Battery Storage High-Capacity Portable Energy Solutions for High Demands

13kWh 15kWh DB Lithium Battery Storage High Capacity Portable Energy Solutions For High Demands

Product Description

The DB Large Capacity Battery with Roller Series (13kWh, 15kWh) is designed for users who require high-capacity, portable energy storage solutions with easy mobility. Built with advanced LFP (Lithium Iron Phosphate) technology, these batteries offer exceptional safety, longevity, and performance. The inclusion of rollers ensures that these high-capacity units can be easily moved and positioned wherever needed, making them ideal for applications that demand flexibility and convenience. The intelligent battery management system (BMS) continuously monitors the battery status, providing real-time protection and ensuring optimal performance. This series is also designed to be environmentally adaptable, with a wide operating temperature range from -20°C to 60°C, ensuring stable and reliable performance in diverse conditions.

Total 4 Model

Technical specifications
Model DDDKYG51240 DDDKYG51280 DDDLSG51300 DDDLSG51314
Battery
Cell Chemistry LFP
Cell Configuration 16S1P 8S1P
Nominal Energy (Wh) 12288 14336 15360 16077
Nominal Capacity(Ah) 240 280 300 314
Nominal Votage(V) 51.2
Working Voltage
Range (VDC)		 43.2~57.6 21.6~28.8
Max.Charge/
Discharge Current(A)		 200 280 100
BMS Communication CAN2.0/RS485/RS232

General Information
Dimension[L*W*H](mm) 505*320*740 460*240*871.5 460*240*837 460*240*871.5
Packing Dimension
[L*W*HJ(mm)		 600*425*468 560*330*950 560*330*910 560*330*950
Weight (kg) 120 130 118 130
Packing Weight (kg) 130 145 136 145
Permissible Altitude(m) <4000m(>2000m derating)
DispalyScreen LCD
IP Rating IP21
Working Temperature
(℃)		 -20~60
Relative Humidity 0~95%,no condensation
Cycle Life 6000 cycles
Warranty 5years
Installation Type Portable
Certification IEC62619/EN61000-6-1/EN61000-3/RoHS/UN38.3

Application

The DB Large Capacity Battery with Roller Series is perfect for scenarios where high energy demands meet the need for portability and flexibility. These batteries are especially suitable for temporary installations, emergency power supply setups, and locations where quick, easy access to power is critical. The combination of high capacity and mobility makes this series an excellent choice for event organizers, mobile operations, and businesses requiring a reliable backup power source that can be easily relocated. The robust design and strong environmental adaptability ensure that these batteries can perform reliably in various challenging conditions.

Shipping Methods

Supports global air and sea shipping
