Cabin Residential Traction Elevator PVC Floor Home Cabin Lift FUJI System
Cabin Residential Traction Elevator PVC Floor Home Cabin Lift FUJI System
Specifications
Brand Name :
FUJI
Model Number :
TKW1600
Certification :
TUV CE EN81 ISO9001
Place of Origin :
Zhejiang China
MOQ :
2Unit
Price :
USD 10000-14000
Payment Terms :
L/C, D/P, T/T, Western Union
Supply Ability :
10000 Units Per Month
Delivery Time :
15 Days
Packaging Details :
Carton Case , Wooden Case
Key Words :
Painted Steel Traction Home Elevator
Cabin :
Painted Steel, 304 Steel
Door :
Painted Steel
Floor :
PVC
Type :
Small Machine Room
Motor :
Gearless
Control :
VVVF AC FUJI
Description

Economic Residential Elevator Painted Steel Cabin FUJI System

Home Elevator fully respect the integrity of the building, using humanized design, world-dass technology, focusing the beauty of the details, supplemented with modem and elegant decoration, creating a noble space exactly with the same taste of villa. At the same time, in view of the personalized demand, we provide exclusive custom to comprehensively enhance the value of house. The home elevator doesn’t need special shaft and can be installed in your home quickly and easily at any point during the construction stage or even later.


Advantage
1. Data Network Signal Transmission System Initiated by Mitsubishi Motor of Japan.
2. AC Voltage Converter Based on Vector Control
3. High Integration Design of Electrical Control System
4. Data Network Signal Transmission System Initiated by FUJI Motor of Japan
5. A New Type of Linkage-Free Portal Crane Structure
6. Design concept based on people-oriented
7. Operational mode and function suitable for residential buildings
8. Energy saving
9. Weighing Start

Residential Passenger Car Decoration:

Passenger elevator Passenger elevator
optional optional
Ceiling Acrylic lightying decoration, stainless steol mirror Acrylic lightying decoration, stainless steol hairline
Car Wall Stainless steel hairline , stainless steol mirror Etched mirroc. stainless steel hairline
Handrail Stainless steel hairline Stainless steel flat handrail
Floor Standard PVC (optional marble) Standard PVC (optional marble)
Open type Center opening Center opening




Details Type Of Specificaton :


Model


Load
KG


Passenger
No.


Speed
m/s

Car specification
CWxCD
(mm)

Door opening
JJxOPH
(mm)

Pit depth
Pit
(mm)

Top floor height
OH
(mm)


POWER
TKJ450/1.0


450


6

 1


1100x1100


700x2100

 1400 4400 3.1
TKJ450/1.5 1.5 1500 4500 4.7
TKJ630/1.0


630


8

 1


1400x1100


800x2100

 1400 4400 4.2
TKJ630/1.5 1.5 1500 4500 6.4
TKJ630/1.75 1.75 1600 4600 7.5
TKJ800/1.0


800


10

 1


1400x1350


800x2100

 1400 4400 5.4
TKJ800/1.5 1.5 1500 4500 8.1
TKJ800/1.75 1.75 1600 4600 9.4
TKJ1000/1.0


1000


13

 1


1600x1400


900x2100

 1400 4400 6.7
TKJ1000/1.5 1.5 1500 4500 10
TKJ1000/1.75 1.75 1600 4600 11.7
TKJ1150/1.0


1150


15

 1


1900x1400


1000x2100

 1400 4400 7.8
TKJ1150/1.5 1.5 1500 4500 11.7
TKJ1150/1.75 1.75 1600 4600 13.6
TKJ1250/1.0


1250


16

 1


1900x1500


1100x2100

 1400 4500 8.5
TKJ1250/1.5 1.5 1500 4600 12.7
TKJ1250/1.75 1.75 1600 4700 14.9
TKJ1350/1.0


1350


18

 1


1900x1600


1100x2100

 1400 4500 9.2
TKJ350/1.5 1.5 1500 4600 13.8
TKJ1350/1.75 1.75 1600 4700 16.1
TKJ1600/1.0


1600


21

 1


1900x1750


1200x2100

 1400 4500 11
TKJ1600/1.5 1.5 1500 4600 16.6
TKJ1600/1.75 1.75 1600 4700 19.4


(Teh data is for design reference only. Regarding detailed parameters, please take technical drawing as criterion.)
Note: If specification exceeds above range, please contact FUJI Elevator Company.

Cabin Residential Traction Elevator PVC Floor Home Cabin Lift FUJI SystemCabin Residential Traction Elevator PVC Floor Home Cabin Lift FUJI System

Cabin Residential Traction Elevator PVC Floor Home Cabin Lift FUJI SystemCabin Residential Traction Elevator PVC Floor Home Cabin Lift FUJI System

FAQ :
Q1: How do you supply after service ?
We will free replace for first years , over one year need pay some cost .
Q2: Can you supply engineer to oversea to help installation .
We are do technical support online ,by phone wechat or whatsapp .
Q3: Can we use our company logo ?
Yes we also can OEM for your Company .
Q4: Whats your company payment terms .
We are 30% before production and 70% before delivery .
Q5: Do you have installation manual and video
Yes we have installation drawing ,manual and video.
