Specifications
Brand Name :
China
Model Number :
JingCaiYuan
Certification :
CE ROHS
Place of Origin :
LED transparent screen indoor P3.91 full color screen
MOQ :
10 square
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
8000㎡/month
Delivery Time :
10-15 days
Packaging Details :
Wooden box
Product name :
transparent Led window display Led glass panel poster
Display function :
Video
Color :
Black Silver
Cabinet size :
Cabinet size
Pixel distance :
2.5*7.8mm
Maximum power consumption :
800W
Description

Wall Mount Transparent LED Window Display Stable Performance Long Lifespan

Product Description

1. 80% transparency, suitable glass wall building advertising use.

2. P3.75/P5/P7.5/P10 models for choice, and 63inch/73inch size for choice.

3. super thin, light weight,only 10Kg per square meter, easy to move and install.

4. about installation, support hanging and floor stand.

5. support all formats videos, pictures, messages, flash, animation,etc.

6. Application: shopping mall, chain store, 4S store, showroom, airport, bank, hotel,etc.

Description

  • The transparent screen is a display with high transparency. Using the principle of the louver structure of the LED display, the gap is formed by the light bar to form a transparent transmittance of >75%, and the light and ventilation are illuminating, which does not affect the lighting and the line of sight.
  • Seamless stitching meets the pursuit of a more beautiful picture of our team,
  • Flexible installation can use video extension technology for any size, ensuring that the picture is not distorted when viewing images, and the color is not distorted.
  • The transparent screen consists of a strip-shaped module structure and a custom design PCB board. It can be spliced into any shape and any shape of the special shape screen, such as stars, characters, patterns, patterns and other different arrangements, beautiful and stylish.

Application:

Full color screens are widely used in government and enterprise projects, exhibitions, cultural tourism, commercial real estate, outdoor advertising media and other fields. For example: supermarkets, restaurants, travel agencies, commercial plazas, cinemas,

Clubhouses, schools, hotels, hospitals, communities, commercial buildings, subway stations, airports, etc.

In short, many places need LED screens for various purposes, we just do our best to meet.

Specification (parameter):

Serial number Item Parameter/Specification
1 Pixel spacing W3.91mm*H7.81mm
2 Best line of sight (M) 4M-12M
3 permeability 70%
4 pixels /㎡ 32768
5 maximum power consumption/㎡ 800W
6 playback power consumption/㎡ 340W
7 Box size(mm) W1000mm*H500mm*D50mm
8 cabinet resolution 256*64
9 Scanning method 1/7
10 box weight (KG) 5kg
11 Display brightness(nits) ≥1500CD/㎡
12 LED package mode 2121 RGB
13 Screen refresh rate ≥3840Hz
14 degree of protection IP30
15 grayscale 16bit
16 brightness adjustment 256级
17 screen material aluminum frame + light bar
18 driver IC Ming Yang 9866
19 Control System Nova
20 Display interface Terminal DIV/HDMI
21 screen power supply Original power supply / LED dedicated power supply
22 Operating voltage 220±5% / 170±5% →DC5V (Display)
23 input voltage AC170~240V 50Hz
24 working environment ﹣10℃~40℃
25 Installation method According to the site, it can be hoisted and fixed.
26 Warranty 2 years warranty
27 LEDlamp life The theoretical service life is 100,000 hours

Competitive advantages:

  • Installation service, usually we are not responsible for overseas installation, but we can
  • Provide technical support for you. If you need to install the service, we can send us
  • Technicians come to your country, but the cost is paid by the customer.
  • Free lifetime maintenance and software upgrades.
  • If you have any questions about the led display, we will reply you within 24 hours.
  • Provide maintenance instructions and problem resolution within 48 hours.
  • Provide customers with loaders so they can be used immediately after installation
  • Led display, no need to debug
  • Free technical training on how to use and process software.
