Screen Small Pitch LED Display IP43 Protection Degree Dust Proof 60Hz Frame Rate
P1.25 small pixel pitch LED display adopts unique intelligent brightness adjustment technology, brightness is adjustable from 0-1200cd/m2. It can automatically adjust the brightness according to the brightness and darkness of the surrounding environment. P1.25 small pixel pitch LED display has a vertical and horizontal bidirectional ≥170 degree super wide viewing angle, and the display coverage area is larger, the image is always perfectly seamless. P1.25 small pixel pitch LED display adopts a cast aluminum cabinet, which is high-strength, ultra-thin and light-weight, convenient for installation and handling, and greatly saves the space.
Details
1. Modular design for quick installation and removal
2. Highly reliable data hot backup, avoiding any communication risks during the exhibition
3. High refresh rate up to 4200Hz, and live video without flashing at all
4. Super brightness and color uniformity, pixel calibration before leaving the factory
5. Horizontal / vertical viewing angle up to 120° uniform HD display, no color cast, no color spots, no color blocks
Application:
Full color screens are widely used in government and enterprise projects, exhibitions, cultural tourism, commercial real estate, outdoor advertising media and other fields. For example: supermarkets, restaurants, travel agencies, commercial plazas, cinemas, clubs, schools, hotels, hospitals, communities, commercial buildings, subway stations, airports, etc.
In short, many places need led screens for various purposes, we will do our best to meet trends and needs.
Description:
Module size:200*150mm | Module resolution:160*120 |
Module type: light and drive in one | Drive mode: constant current drive |
Module working voltage: +4.2V | Point spacing:1.25mm |
Module average power: 12W | Pixel composition:1R1G1B |
Module maximum power: 26W | Vertical viewing angle:140° |
Specification (parameter):
Unit cabinet
Module distribution | 2*2 block |
Cabinet resolution | 320*240 |
Maximum power of cabinet | 104W |
Cabinet average power | 52W |
Module uniformity | <5% |
Cabinet size | 400*300mm |
Cabinet color | black, grey |
Protection degree (front/back) | IP43 |
Full screen
Application | indoor |
White balance brightness | ≥700cd/m2 |
Color temperature | 9600K |
Pixel density (dots/square meter) | 640000 |
Power supply | AC220V/50HZ AC110/60HZ |
Earth leakage current | <2mA |
Working temperature | -25℃ to 45℃ |
Working environment humidity | 10%-50% |
Environmental temperature | -40℃ to 80℃ |
Frame change frequency | 60Hz |
Refresh rate | ≥3000Hz |
Optimum line of sight | ≥1.25m |
Grayscale/color | 281 trillion |
Brightness adjustment software | Software 16-level adjustment / 16-level automatic |
control mode | Synchronized displays with computer screen |
