IP Network Car Roof Mobile IP66 Waterproof PTZ Camera 30X / 20X Optical Zoom
IP Network Car Roof Mobile IP66 Waterproof PTZ Camera 30X / 20X Optical Zoom
IP Network Car Roof Mobile IP66 Waterproof PTZ Camera 30X / 20X Optical Zoom
IP Network Car Roof Mobile IP66 Waterproof PTZ Camera 30X / 20X Optical Zoom
Specifications
Brand Name :
WINSAFE
Model Number :
AC3-S3002N-IR
Certification :
CE/FCC
Place of Origin :
CHINA
MOQ :
1
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
6000PCS/Month
Delivery Time :
5 - 8 Work Days
Packaging Details :
Neutral Packing
Active Pixel :
1920(H) x 1080(V)
Signal System(SD） :
PAL / NTSC
White Balance :
Auto
Focus :
Auto / Manual
Optical Zoom :
20X / 30X
Digital Zoom :
12X
IR Wave Length :
850nm
IR Distance :
60M
Description


IP Network Car Roof Mobile IP66 Waterproof PTZ Camera 30X / 20X Optical Zoom


Features

※ 1/2.8” CMOS, 2.13MP, 30X/20X optical zoom;
※ Network video maximum support 1080P30;
※ Support CVBS standard clear video output;
※ Support H.265, H.264 video compression, support dual stream;
※ Support multi level video quality configuration;
※ ONVIF & RTSP Compliant;
※ Efficient 60m IR distance;
※ Wide dynamic range, ICR day/night;
※ Digital image stabilization;
※ Soft PTZ address, protocol and baud rate self-adpative;
※ Waterproof index: IP66;
※ 10.8~28V voltage input;
※ Auto power-off with low power supply.


Technical Specification

Model No.AC3-S2008N-IRAC3-S3002N
Camera
Image Sensor1/2.8" Progressive Scan CMOS,2.13MP
Active Pixel1920(H) x 1080(V)
Signal Sytem(NET)HD:1080p30 / 1080p25 / 720p60 / 720p50 / 720p30 / 720p25
Signal System(SD)PAL / NTSC
Min.IlluminationColor: 0.0013Lux; B/W:0.0008Lux
White BalanceAuto
FocusAuto / Manual
ExposureAuto / Manual
S/N RatioNote less than 50 Db
BLCOn / Off
WDROn / Off
Digital Noise Reduction1 - 5Steps/OFFOn/Off
Digital Image StabilizationNo
Day/NightAuto / Manual
Lens
Optical Zoom20X30X
Digital Zoom12X
Lensf=4.7mm - 94mmf=4.3mm - 129mm
IRISF1.6 - F3.5F1.6 - F4.7
View Angle59.5° (wide) to 3.3° (tele)63.7° (wide) to 2.3° (tele)
PTZ
Pan Range360° Continuous
Pan Speed0.1° - 60°/s, adjustable, Preset Speed: 60°/s
Tilt Range- 15 ° - 90° with auto flip
Tilt Speed0.2° - 60°/s, adjustable, Preset Speed:60°/s
Preset Number256
Preset Precision±0.2°
IR Light
IR Wave Length850nm
Range60m
SwitchAuto / Manual
Network
Image Resolution1920 x 1080@30fps
Image CompressionH.264, H.265
Audio CompressionAAC
ProtocolHTTP, RTSP, TCP, UDP, ONVIF
No.of User AccessUp to 10
Dual StreamSupport
Interface
Audio Interface1 Line in, 1 Line out
Video Output(SD)CVBS1.0V(p-p)/75Ω PAL or NTSC(optional)
Ethernet InterfaceRJ45, 10/100M
Comm. InterfaceRS-485
General
OSD LanuageEnglish
Address0 - 255
Comm.ProtocolPELCO-P / PLECO-D(self-adaptive)
Protocol2400bps, 4800bps,9600pbs,19200bps(self-adaptive)
VoltageDC 10.8 - 28V
PowerMin: 9W; Max: 20W
Working Temperature-35°C - +65°C
IP CodeIP66
DimensionsStandard(Without Damper): Φ136(mm) x 185(mm)
WeightStandard(Without Damper): 2.1(±0.2)kg





Dimensional Drwing

IP Network Car Roof Mobile IP66 Waterproof PTZ Camera 30X / 20X Optical Zoom

IP Network Car Roof Mobile IP66 Waterproof PTZ Camera 30X / 20X Optical Zoom
