Wifi Tuya IP66 Waterproof Access Control System Touch Keypad RFID Card Reader Standalone Access Control with TTLock Door
Wifi Tuya IP66 Waterproof Access Control System Touch Keypad RFID Card Reader Standalone Access Control with TTLock Door
Wifi Tuya IP66 Waterproof Access Control System Touch Keypad RFID Card Reader Standalone Access Control with TTLock Door
Wifi Tuya IP66 Waterproof Access Control System Touch Keypad RFID Card Reader Standalone Access Control with TTLock Door
Wifi Tuya IP66 Waterproof Access Control System Touch Keypad RFID Card Reader Standalone Access Control with TTLock Door
Wifi Tuya IP66 Waterproof Access Control System Touch Keypad RFID Card Reader Standalone Access Control with TTLock Door
Wifi Tuya IP66 Waterproof Access Control System Touch Keypad RFID Card Reader Standalone Access Control with TTLock Door
Wifi Tuya IP66 Waterproof Access Control System Touch Keypad RFID Card Reader Standalone Access Control with TTLock Door
Wifi Tuya IP66 Waterproof Access Control System Touch Keypad RFID Card Reader Standalone Access Control with TTLock Door
Wifi Tuya IP66 Waterproof Access Control System Touch Keypad RFID Card Reader Standalone Access Control with TTLock Door
Wifi Tuya IP66 Waterproof Access Control System Touch Keypad RFID Card Reader Standalone Access Control with TTLock Door
Wifi Tuya IP66 Waterproof Access Control System Touch Keypad RFID Card Reader Standalone Access Control with TTLock Door
Specifications
Brand Name :
VANSHUI
Model Number :
GL-AC03
Certification :
CE,FCC
Place of Origin :
SHANGHAI,CHINA
MOQ :
1pcs
Price :
Negotiation
Payment Terms :
T/T, Western Union,Paypal
Supply Ability :
1000Pcs/month
Packaging Details :
Unit Pacakge:15.6*7.6*6.6cm,G.W.:0.615kg Carton Package:47*30*18.2cm,G.W.12.5kg,20units/CTN
Delivery Time :
sample order within 3-4days.
Type :
APP+PASSWORD+RFID Card
Customized support :
Customized logo, TT LOCK or TUYA APP Control
Special Features :
Weatherproof, Door Bell Button
Waterproof Rank :
IP66
Proximity Card Reader :
125KHz(ID carfd) or 13.56MHz(IC card)
Wiring Connections :
Relay output, exit button, alarm, door contact, Wiegand input/output
Relay :
One (NO, NC, Common)
Adjustable Relay Output Time :
0~99 Seconds (5 seconds default)
Description
PRODUCT DESCRIPTION
IP66 Waterproof Wireless Remote Control TTLOCK PIN+Card Access Control Terminal
TUYA Door Access Control Reader Keypad
FEATURES
Outdoor Touch Keypad & Reader
>Touch keypad with doorbell
>One relay,1000 users (988 common users + 2 panic users +10 visitor users)
>Card Type:125KHz EM Card/13.56Mhz Mifare Card
>Wiegand 26~44bits,56bits,58 bits input & output
>Can be used as Wiegand reader with LED & buzzer output
>User data can be transferred
>Integrated alarm & Buzzer output
>Built-in light dependent resistor(LDR) for anti tamper
>Backlit keypad,can set automatic OFF after 20 seconds
>2 devices can be interlocked for 2 doors
>BT function or Big user capacitive for optional
SPECIFICATION
Model
GL-AC03
User Capacity
1000 users (988 common users + 2 panic users +10 visitor users)
PIN Length
4~6 digits
Operating Voltage
12~28V AC/DC
Idle Current
≤ 60mA
Active Current
≤ 150mA
Proximity Card Reader
EM or Mifare
Radio Technology
125KHz/13.56MHz
Read Range
2~6cm
Wiring Connections
Relay output, exit button, alarm, door contact, Wiegand input/output
Relay
One (NO, NC, Common)
Adjustable Relay Output Time
0~99 Seconds (5 seconds default)
Lock Output Load
2 Amp Maximum
Wiegand Interface
EM card version: Wiegand 26~44 bits input & output
(Factory default: Wiegand 26bits)
Mifare card version:Wiegand 26~44 bits,56bits,58bits input & output
(Factory default: Wiegand 34bits)
PIN Output
4 bits,8bits (ASCII),10 digits Virtual Number(Factory default:4bits)
Environment
IP66
Operating Temperature
-40°C ~ 60°C (-40°F ~ 140°F)
Operating Humidity
0%RH ~ 98%RH
Physical
Zinc-Alloy
Color
Sliver
Dimensions
L145 x W68 x H25 (mm)
Weight
Unit Weight:1KG;Shipping Weight:1.5KG
DIAGRAM
DETAILS
PRODUCTS PACKAGE
APP INTRODUCTION
