Specifications
Brand Name :
VANSHUI
Model Number :
QR300
Certification :
CE,FCC
Place of Origin :
SHANGHAI,CHINA
MOQ :
1pcs
Price :
Negotiation
Payment Terms :
T/T, Western Union,Paypal
Supply Ability :
1000Pcs/month
Packaging Details :
Selling Units: Single item Single package size: 10X10X6 cm Single gross weight: 1.000 kg Package Type: one piece in one box, 50 pieces in one carton
Delivery Time :
sample order within 3-4days.
Frequency :
125KHz+13.56Mhz+QR code
Communicate :
Wiegand 26/34bits & RS485
Identification method :
QR code|IC card|ID card|NFC card
Reading angle :
Rotation angle 360°,elevation angle±65°
Scanning angle :
75°(horizontal),55°(vertical),85°(diagonal)
Support QR code format :
QR Code, Data Matrix(optional),PDF417(optional),etc.
Store users :
30,000
Reading Speed :
<200 milliseconds
Description

RFID Card and QR Code Access Control Turnstile QR code access control reader with USB,RS232 or TCP/IP Interface

Products Description
Features
QR300 QR code access control card reader is a high-end smart access control card reader with a standard 86 structure and ABS material shell; the panel is made of 9H tempered glass, which has high scratch resistance and high explosion resistance; IPX7 waterproof internal potting and sealing treatment is comprehensive Waterproof; dual-lamp supplement light high-definition scanning has wide view ingangle, fast speed, high recognition rate, strong compatibility, and can be connected to any brand access controller that supports Wiegand/RS485 ommunication. Currently, it is widely used in commercial office buildings, real estate, scenic tourism, and communities Visitor access management, supporting gates,access control, visitor machines, smart homes, etc.
Specification
Model
QR100
Product Description
RFID +QR code reader
Communicate
Wiegand 26/34bits & RS485
Identification method
QR code|IC card|ID card|NFC card
(At the same time can support NFC, ID, QR code authentication)
Reading angle
Rotation angle 360°,elevation angle±65°,deflection angle±65°
Scanning angle
75°(horizontal),55°(vertical),85°(diagonal)
Support QR code format
QR Code, Data Matrix(optional),PDF417(optional),etc.
Store users
30,000
Operating temperature
-20℃to 60℃
Relative humidity
5% to 95%
Ambient light
Direct sunlight, micro light source at night
Reading Speed
<200 milliseconds
Input power
DC12V 500mA (support wide voltage 5~30V)
physical dimension
86*86*13 mm
Recognition distance
Standard distance 5-30 cm
QR code support range
Wiegand 26-bit support range (0-255),(1-65535);
Wiegand 34-bit support range 1-42949672;
RS485 support range is 1024 characters
Working Application
