Aluminium / Copper Brazing Furnace , Furnace Brazing Process Easy Maintenance
Aluminium / Copper Brazing Furnace , Furnace Brazing Process Easy Maintenance
Specifications
Brand Name :
Aojie
Model Number :
RCWE 12-13×180×8, RCWE 12-18×260×16, RCWE 12-22×260×16, RCWE 12-22×300×16, RCWE 9-31×280×30, RCWE 12-31×300×16, RCWE 12-31×300×22, RCWE 12-35×350×20,RCWE12- 40×350×24,RCWE12- 42×350×30,RCWE12- 42×450×16,RCWE12- 45×450×16,RCWE12- 45×350×30,RCWE6- 58×650×10,
Certification :
Certificate of machinery an low voltage directives
Place of Origin :
China
MOQ :
1 set
Price :
negotiable
Payment Terms :
T/T
Supply Ability :
150 sets per year
Delivery Time :
16 working weeks - 24 working weeks
Packaging Details :
It depends on the size and dimension of the equipment.
Rated Power(kw) :
120/145/150/168/200
Max. Operating Temperture(°C) :
1150
Belt Width(mm) :
420/450/580/600/650
Chamber Dimension(W×L×Hmm) :
460×4500×160/490×4500×160/490×3500×300/630×6500×100/660×4600×160/700×4500×140
Origin :
China
Description

Imported Materials , High Temperature Brazing, Continous Controlled Atmosphere

Overview

Continuous high temperature brazing furnace is a continuous working heat treatment production line which is mainly used to control the forming of powder metallurgy products.The production line features advanced control, remarkable energy saving, easy maintenance and quality assurance.

Features

  • Patented heating muffle is guaranteed for 1.5 years under normal condition (1120℃) and 3 years with lower temperatures (less than 950℃).
  • Cooling muffle is under the examination and approval for invention patent, and guarantees the brazing parts will be bright and shiny without oxidation.
  • Cooling section is equipped with heat exchanger, which greatly improves cooling speed.
  • Automatic control with multiple protective solutions assure the safety of both furnace and operators.

Model
RCWE12-
42×450×16
RCWE12-
45×450×16
RCWE12-
45×350×30
RCWE6-
58×650×10
RCWE12-
60×460×16
RCWE12-
65×450×14

Rated

Power

 120 145 145 168 150 200
Max Operating Temperature 1150 1150 1150 650 1150 1150
Belt Width(mm) 420 450 450 580 600 650

Work Zone

(W×L×Hmm)

 460×4500×160 490×4500×160 490×3500×300 630×6500×100 660×4600×160 700×4500×140
Protective Atmosphere Exothermic, Dissociated Ammonia, Mixed Nitrogen Hydrogen, Pure Hydrogen
