Small Deformation , Aluminum Brazing Furnace , Wide Range Temperature Control

Overview

Aluminum brazing furnace is a kind of brazing equipment for the aluminum radiator suitable for the brazing process of aluminum radiator, condenser, evaporator, oil cooler and other products. It is widely used in electronic, appliances, aerospace, military equipment, wind power equipment fields and so on.

Continuous protective atmosphere brazing furnace is designed with reasonable structure and uniform furnace, the workpieces can be transmit stably with small deformation through the conveyor. The size of the furnace can be designed and manufactured according to the specifications and sizes of different products of users and the production capacity.

Features

• High performance refractory material is adopted to ensure the superior insulation feature of the furnace with low energy consumption while empty load. The excellent designing and manufacturing of the gas distribution system and atmosphere curtain of the furnace ensure the low consumption of purified nitrogen and save the furnace atmosphere so as to decrease the production cost.
• The biggest advantage of this type of furnace is that it is applicable to wide range temperature control, suitable for ceramic brazing, ceramic and metal welding, as well as soft/hard brazing of various metal materials. It is equipped with intelligent PID temperature control system to achieve high precision and stability of temperature control.

Hard brazing

Brazing solder has a melting point of more than 450°C and high joint strength,The strength of hard brazing joints is high, some kinds of brazing solders can be used in high temperature. There are many kinds of solder for hard brazing, the most widely used solder based on aluminum, silver, copper, manganese and nickel. Aluminum base solder is often used for brazing aluminum products.Silver base copper filler metal is often used for brazing copper and iron parts.

Aluminum Brazing Furnace Parameters
