Pneumatic Office Chair Cylinder For Bar Chair Qpq 140mm Hydraulic Adjuster
Pneumatic Office Chair Cylinder For Bar Chair Qpq 140mm Hydraulic Adjuster
Pneumatic Office Chair Cylinder For Bar Chair Qpq 140mm Hydraulic Adjuster
Pneumatic Office Chair Cylinder For Bar Chair Qpq 140mm Hydraulic Adjuster
Specifications
Brand Name :
NANTAI OR CUSTOMIZED
Model Number :
140
Certification :
BIFMA5.1 SGS TUV
Place of Origin :
CHANGZHOU ,CHINA
MOQ :
500 pieces
Price :
Negotiable
Payment Terms :
T/T, Western Union, L/C Negotiable
Supply Ability :
1200000 pieces per month
Delivery Time :
7-15 working days
Packaging Details :
1. 1pc per poly bag 20pcs per carton 3. 22000pcs-25000 pcs per 20GP
Product Name :
Pneumatic Gas Springs
Stroke :
140mm
Material :
Steel/Iron
Usage :
Bar Chair
Packing :
10pcs/ctn
Color :
Chrome/Black
Pressure :
380-440N
Certificate :
SGS AND TUV
Button :
White/ Orange/ Green/ Blue/Customized
Bottom Dealing :
Welding/ Punched
Description

Pneumatic Office Chair Cylinder For Bar Chair Qpq 140mm Hydraulic Adjuster

140mm gas springs are designed to adjust the height of office chairs and the position of office chairs. it can be rotated 360° smoothly. And its load capacity is 75kg-300kg, We also can offer any color of surface you need, QPQ is a kind of special treatment for inner tube, it is used for the high-quality chairs.

Pneumatic Gas Springs Products Features:

  • The extended Length: 414mm
  • Stroke: 140mm
  • Outer tube length: 255mm
  • Froce:380mm-440mm
  • Application: Office Chair
  • Certification: BIFMA5.1 SGS TUV
  • Class: Class1/2/3/4
  • Class 3: Inner Tube Φ28 thickness is 2.5mm, Outer Tube Φ50 thickness is 1.5mm
  • Quality Guarantee: 3-5 years
  • Button color: white, orange,blue according to your reuquest
  • Package: 1pcs in a poly bag, 20pcs in one carton, 60ctns in one pallet
  • MOQ: 500pcs
  • Bottom Dealing: Punched or Welding
  • Surface: Inner tube is QPQ treatment, Outer tube is Black

Pneumatic Gas Springs ​Highlights:

Colors: Black/White
NOTE: We offer 5 sizes and 2 colors of Replacement Gas Lift Cylinders for Universal Standard Size chairs. Please determine what sizes and colors you want before you add to cart.

About the extension of cylinders, please choose product options and refer to the picture description.
Adjustable ranges:
65, 85, 100, 120, 140 mm
( 2.6, 3.5, 4, 4.7, 5.5 inch)

These replacement office chair gas lift cylinders are more heavy duty than standard chair gas lift cylinders.
It is a great replacement option for damaged or worn out gas lifts on office chairs, task chairs, executive chairs.

Pneumatic Gas Springs Company Introduction:

Changzhou Nantai gas spring Co., Ltd. was founded in 2004, which designs and researches, manufactures, sells and offers overall after-sell service independently. Our products cover gas spring for swivel chairs, lockable gas spring and compression gas spring for furniture. We have achieved long-term cooperation with more than 30 countries all around the world. Nantai keeps developing, and has a high-tech, high-quality management team, constantly improves our products quality according to the demand of market. Our advanced product quality gets a good reputation among our domestic and foreign customers. Quality Management System ISO9001:2016, Germany TUV LGA (DIN4550) and BIFMA5.1 SGS are our certifications.


Pneumatic Gas Springs Products Drawing and Pic:


Pneumatic Office Chair Cylinder For Bar Chair Qpq 140mm Hydraulic Adjuster
C: Stroke length (mm)
L: Extended length (mm)
V: Outer tube length(mm)
X+Y: Taper length (mm)

MODEL
L (MM)
C (MM)
V (MM)
X (MM)
Y (MM)
(F2)N
40MM
230
40
145
58
10
460
60MM
275
60
160
58
10
460
80MM
305
80
175
58
10
460
100MM
347
100
195
58
10
440
120MM
392
120
215
58
10
420
140MM
414
140
225
58
10
420
160MM
450
160
250
58
10
420
180MM
525
180
275
58
10
420
200MM
545
200
295
58
10
420
230MM
680
230
370
58
10
420
260MM
705
260
385
58
10
420

Pneumatic Office Chair Cylinder For Bar Chair Qpq 140mm Hydraulic Adjuster
