Anti-leakage Power-off Switch Knob Type Rotary Battery Disconnect Master Switch

This battery disconnect switch is used with alternator cutoff, which features safety , theft protection and easy installation. Die cast zinc alloy housing , die cast lever, connecting brass slips, insulation slips, springs and structure have been improved in last 8 years step by step go guarantee reliable performance.

Specification of Anti-leakage Power-off Switch Knob Type Rotary Battery Disconnect Master Switch

[Product Voltage] : 12-24V
[Rated current] : 300A
[Instantaneous current] : 1000A
[Screw hole diameter] : 10MM
[Electrical lifespan] : 1000 times
[Product material]: aluminum alloy + brass + copper
[Product Features] : Heavy duty metal shell, can be used in harsh environments
[Scope of application] : Cars, RVs, yachts, trucks, trucks

Features of Anti-leakage Power-off Switch Knob Type Rotary Battery Disconnect Master Switch

Our New Heavy Duty Master Battery Disconnect Switch is mainly control power supply

Universal apply for street roads, RVs, trailers, or just about any vehicle where a battery cut off switch is required

Quality guaranteed: Water proof,durable,easy to control,ensure the vehicle electrical system reliability and stability

Aluminum housing and heavy duty

Application of Anti-leakage Power-off Switch Knob Type Rotary Battery Disconnect Master Switch

Can be used as interior and exterior of the increase in all kinds of electrical devices on / off key (eg: Strobe, chassis lights,
fog lights).

Easy To Install In A Minute

1. Disconnect battery.

2. Determine negative cable.

3. Choose suitable mounting position for switch. (you can drill a hole at the thread of the handle.

4. Install switch. Please refer to the wiring diagram in the instructions.

NOTE: Do not attach positive and negative cables to shutoff switch at the same time. Otherwise, battery explosion may result.

5. Reconnect battery and check for correct operation.

NOTE: Be sure ignition switch is in OFF position before turning shut-off switch to OFF position to eliminate voltage spikes that could damage ignition components.

Package Included

1 x Battery Disconnect Switch
