250V 6.3A PCB Mount Fuse Holder 20mm Bayonet For Horizontal Terminal
250V 6.3A PCB Mount Fuse Holder 20mm Bayonet For Horizontal Terminal
250V 6.3A PCB Mount Fuse Holder 20mm Bayonet For Horizontal Terminal
250V 6.3A PCB Mount Fuse Holder 20mm Bayonet For Horizontal Terminal
250V 6.3A PCB Mount Fuse Holder 20mm Bayonet For Horizontal Terminal
250V 6.3A PCB Mount Fuse Holder 20mm Bayonet For Horizontal Terminal
250V 6.3A PCB Mount Fuse Holder 20mm Bayonet For Horizontal Terminal
250V 6.3A PCB Mount Fuse Holder 20mm Bayonet For Horizontal Terminal
250V 6.3A PCB Mount Fuse Holder 20mm Bayonet For Horizontal Terminal
250V 6.3A PCB Mount Fuse Holder 20mm Bayonet For Horizontal Terminal
250V 6.3A PCB Mount Fuse Holder 20mm Bayonet For Horizontal Terminal
250V 6.3A PCB Mount Fuse Holder 20mm Bayonet For Horizontal Terminal
Specifications
Model Number :
PTF-50
Certification :
UL CSA VDE CE
Place of Origin :
China
MOQ :
1000
Price :
USD $0.25~$0.5 per piece
Payment Terms :
T/T
Supply Ability :
5K pieces per week
Delivery Time :
10 work days
Packaging Details :
Inner Box, Outer Carton
Item :
Fuse Holder
Mount Type :
PCB mount
Cap Type :
Bayonet
Pin Distance :
10mm
Voltage Rating :
250V
Current Rating :
6.3A
Applied to :
5.2x20 fuses
RoHS Compliant :
Yes
Body Material :
PBT
Terminal Material :
nickel plated brass
Total length :
33.1mm
Cut-out diameter :
13mm
Description

Product Description

For 5x20mm FUSES

  • Contact Resistance: <0.005Ω
  • Withstanding Voltage: >AC3000V
  • lnsulation Resistance: 100mΩ Min
  • Electrical:Rated at 6.3A 250V AC
  • Operation Power: 2.5W
  • Mouting hole diameter: 1.3mm
  • UL 94V-0 retardant grade
Item PTF-50 Fuse Holder
Mouting Style PCB Mount
Max Rating 6.3A 250V
Fire retardant grade UL 94V-0
Frame and cap PBT
Terminal nickel plated brass
Fuse Size 5x20mm
Cut-out diameter 13mm

Drawing of PTF-50 fuse holder PCB mount horizontal terminal

250V 6.3A PCB Mount Fuse Holder 20mm Bayonet For Horizontal Terminal

Please allow 1-3mm tolerance due to manual measurement.

Product Features

  • 6.3A 250V AC rating
  • 5.2x20mm fuses
  • Bayonet type cap
  • PCB mounting terminal
  • PBT UL 94V-0 body

250V 6.3A PCB Mount Fuse Holder 20mm Bayonet For Horizontal Terminal

250V 6.3A PCB Mount Fuse Holder 20mm Bayonet For Horizontal Terminal

Standard Package:

100pcs per box, 1000pcs per carton

Shipping Term:

EXW, DDU, DDP, C&F, FOB

Shipping Methods:

International Express, By Air, By Sea
