NTC MF58 Thermistor Temperature Sensor +/-1% +/-5% 3950B 10K 50K 100K Ohm New
NTC MF58 Thermistor Temperature Sensor +/-1% +/-5% 3950B 10K 50K 100K Ohm New
NTC MF58 Thermistor Temperature Sensor +/-1% +/-5% 3950B 10K 50K 100K Ohm New
NTC MF58 Thermistor Temperature Sensor +/-1% +/-5% 3950B 10K 50K 100K Ohm New
NTC MF58 Thermistor Temperature Sensor +/-1% +/-5% 3950B 10K 50K 100K Ohm New
NTC MF58 Thermistor Temperature Sensor +/-1% +/-5% 3950B 10K 50K 100K Ohm New
NTC MF58 Thermistor Temperature Sensor +/-1% +/-5% 3950B 10K 50K 100K Ohm New
NTC MF58 Thermistor Temperature Sensor +/-1% +/-5% 3950B 10K 50K 100K Ohm New
NTC MF58 Thermistor Temperature Sensor +/-1% +/-5% 3950B 10K 50K 100K Ohm New
NTC MF58 Thermistor Temperature Sensor +/-1% +/-5% 3950B 10K 50K 100K Ohm New
Specifications
Brand Name :
Tianrui
Model Number :
MF58
Certification :
ROHS
Place of Origin :
China
MOQ :
2000
Payment Terms :
100% TT,Paypal
Supply Ability :
5000pcs every day
Delivery Time :
7 days
Feature :
Resistance value changes significantly with temp
Case :
Glass Encapsulated
Resistance at 25C :
2K-1000KΩ
B Value :
3470 ~ 4400
Tolerance :
±1%,±2%,±3%,±5%,±10%
Rated Power :
≤50mW
Thermal Time Constant :
20S(In StilI Air)
Operating temp. :
-55 to + 250C
Application :
Temperature measurement and control
Description
Color Red
Product name NTC MF58 Thermistor Temperature Sensor +/-1% +/-5% 3950B 10K 50K 100K Ohm New
Resistance at 25C 2K-1000KΩ
B Value 3470 ~ 4400
Tolerance ±1%~±10%
Leads Axial Leads
Coating Glass Encapsulated
Thermal Time Constant 20S(In StilI Air)
Operation Temperature -55C Up To 250C
Application Temperature measurement and control

NTC MF58 Thermistor Temperature Sensor +/-1% +/-5% 3950B 10K 50K 100K Ohm New

NTC MF58 Thermistor Temperature Sensor +/-1% +/-5% 3950B 10K 50K 100K Ohm New

NTC MF58 Thermistor Temperature Sensor +/-1% +/-5% 3950B 10K 50K 100K Ohm New

NTC MF58 Thermistor Temperature Sensor +/-1% +/-5% 3950B 10K 50K 100K Ohm New

NTC MF58 Thermistor Temperature Sensor +/-1% +/-5% 3950B 10K 50K 100K Ohm New

NTC MF58 Thermistor Temperature Sensor +/-1% +/-5% 3950B 10K 50K 100K Ohm New

Size(mm)

NTC MF58 Thermistor Temperature Sensor +/-1% +/-5% 3950B 10K 50K 100K Ohm New

Part number R25℃(KΩ)

B value

( K)

 Dissipation Coefficent
(mw/°C)		 Time
Constant (S)		 Operating Temperature Range (°C)
MF58-202-3470◊ 2 3470 In still air 2.5max In still air 17max -40- +150°C
M f58-502-3500◊ 5 3500 -40~+150°C
MF58-103-3 435◊ 10 3435 -40- +150°C
MF58- 103-3600◊ 10 3600 -40- +150°C
MF58-473-3950◊ 47 3950 -40~+250°C
MF58-503-3950◊ 50 3950 -40- +250°C
MF58- 104-3990◊ 100 3990 -40- +300°C
MF58-154-4100◊ 150 4100 -40-+300°C
MF58-204-4300◊ 200 4300 -40~+300°C
MF58-105-4400◊ 1000 4400 -40- +300°C


Features

• Good stability and high reliability.

• Wide resistance range and high precision.

• It can be used under harsh conditions such as high temperature and high humidity.

• Small size, light weight, sturdy structure, easy for automatic installation.

• Fast heat induction and high sensitivity.

Application

1.Temperature monitoring and control in automobile industry
2.Temperature monitoring and control of household appliances
3.Precision circuit and crystal oscillator temperature compensation
4.Micro motor speed control
5.Medical device temperature detection and control

NTC MF58 Thermistor Temperature Sensor +/-1% +/-5% 3950B 10K 50K 100K Ohm New

Related types of thermistors and temperature sensors

NTC MF58 Thermistor Temperature Sensor +/-1% +/-5% 3950B 10K 50K 100K Ohm New

NTC MF58 Thermistor Temperature Sensor +/-1% +/-5% 3950B 10K 50K 100K Ohm New

NTC MF58 Thermistor Temperature Sensor +/-1% +/-5% 3950B 10K 50K 100K Ohm New

FAQ

1Q:What can I do if I got a broken product from DONGGUAN TIANRUI?

A:First of all please tell us as soon as possible after we send a new one to you immediately but please send the broken product to us.You don't have to worry about the carriage charge we will pay for that.

2Q:Are we a trader or manufacturer?

A:Both

3Q:Why do you have choose us?

A:High quality. Competive price. Fast shipping.

4Q:What is approval?

A:ROHS of NTC MF58 Thermistor Temperature Sensor +/-1% +/-5% 3950B 10K 50K 100K Ohm New
