Specifications
Brand Name :
Tianrui
Model Number :
TR
Certification :
ROHS
Place of Origin :
China
MOQ :
100pcs
Price :
Negotiable
Payment Terms :
100% TT,Paypal
Supply Ability :
5000pcs every day
Delivery Time :
10-14 days
Packaging Details :
Carton
Current :
30A
Voltage :
32V dc
Working Temperature :
-40℃ to 125℃
Material :
PA+Brass
Application :
Car, Boat, etc
Description
Color Black Base+Transparent Cover
Product Name Waterproof dustproof automotive Car Auto Blade Bus Fuse Holder Block Box without led Indicator 6-way marine
Main Line Input Terminal Rating: M5 thread studs(75A 32V DC.max), intput wire size: #4-6AWG
Single Line Out Put Terminal Rating :20A max per circuit, output wire size:#12-16AWG
Certificate ROHS
Type 6 12 Circuits Way Blade Fuse Box Negative Bus Fuse Block Holder with LED Indicator Damp-Proof Protection Cover
Application Car, SUV, RV, Bus, Yacht, Boat, etc
Packing PE Bag, Paper Box or Customized
Material PA66 Base, PC Cover
Way 6 12 Ways

[Product name]: Long 6-way independent positive and negative multiple-in and multiple-out fuse box
[Product net weight]: 174G
[Product gross weight]: 177G
[Product size]: 12*5*5.2cm
[Single product packaging size]: 18.5*13*5.5cm
[Packing method]: standard PE bag packaging (box customized)
[Input rated voltage]: 32V
[Input rated current]: 75A
[Maximum output current]: 20A per circuit
[Product accessories]: PA66 body, PC dust cover, nickel-plated copper terminal, stainless steel screws, PP×70 stickers
[Main line terminal]: M6 threaded stud (75A 32V DC max)
[Main wire]: #4-6AWG
[Single-wire terminal]: M4 threaded stud (20A 32V DC max)
[Single wire]: #12-16AWG
Accept ATO or ATC fuses from 1A to 20A
[Installation range]: It can be installed on cars, off-road vehicles, RVs, buses, yachts, boats, etc.

[ Fuse function]: When the circuit fault or abnormal, with the current constantly increased, and the increased current may damage some important or valuable components in the circuit, but also may burn down the circuit and even cause a fire.Fuses protect electronic equipment from current damage and avoid serious damage caused by internal malfunction of electronic equipment.Therefore, each fuse has a rated specification, when the current exceeds the rated specification, the fuse will blow.If the fuse is properly installed in the circuit, it will fuse itself to cut off the current when the current rises to a certain height and a certain temperature, thus playing a role in protecting the safe operation of the circuit.

Long Type Blade Fuse Holder

Waterproof Dustproof Automotive Car Auto Blade Bus Fuse Holder Block Box Without Led Indicator 6-way Marine

•Model 8: Blade Fuse Holder with Cable


Waterproof Dustproof Automotive Car Auto Blade Bus Fuse Holder Block Box Without Led Indicator 6-way Marine
