Chemical Containers PVC Sheet Bending Machine 380V DVS Standard
Chemical Containers PVC Sheet Bending Machine 380V DVS Standard
Chemical Containers PVC Sheet Bending Machine 380V DVS Standard
Chemical Containers PVC Sheet Bending Machine 380V DVS Standard
Specifications
Brand Name :
MM-TECH
Model Number :
SWT-ZW3000
Certification :
CE
Place of Origin :
China
MOQ :
1set
Price :
$10000-$11150/ set
Payment Terms :
T/T, Western Union
Supply Ability :
10 sets per week
Delivery Time :
5-8 work days
Packaging Details :
Wooden Box
Product Name :
Sheet Bending Machine
Rated Voltage :
380V, 50/60Hz
Bending Length :
3000
Packing Dimensions :
4330*1900*1850
Air pressure(kg.f/cm²) :
6.0-8.0
Bending Angle(°） :
40-150
Heating Power :
9kw
Rated Current :
36A
Warranty :
2 years
CE Certification :
Yes
Description

SWT - ZW3000 380V DVS Plastic Chemical Containers Sheet Bending Machine

Sheet Bending Machine Brief Introduction:

ZW series Sheet Bending Welding Machine are suitable for welding thermoplastic sheets made of HDPE, PP, PVC, PVDF.

The machine is designed according to DVS 2208, and can operate in compliance with the DVS 2207.


Sheet Bending Machine Specification:

Specification/Size SWT-ZW3000
Weldable sheet thickness(mm) 3.0-30.0
Bending Angle(℃) 40-150℃
Air pressure (kg.f/c㎡) 6.0-8.0
Rated voltage(V) 380V, 50/60Hz
Rated current(A) 6A
Heating Power(KW) 9KW
Rolling Motor Power(KW) 1.5KW
External dimensions(L*W*H) mm 4200*1800*1600
Packing dimensions(L*W*H )mm 4330*1900*1850
N.W KGS 1380kg
G.W KGS 1500kg

Operating Principle:

Heat bending of plastic plates . The plate can be heated on the heating table until it softens in the heated area, after which it is bent and held in a fixture while cooling. Fixtures can be made of MDF board or the like. Since subjects may be taken from the hot stage, immediately after the heating, the method is also suitable for large series. Hot bending may also take place in the hot bending machines, securing the plate during cooling,. This method is mostly used for individual pieces , where you do not want to manufacture fixtures. Most thermoplastics can be Heat Bending, very suitable are PMMA (acrylic), PC (polycarbonate), )and PVC (polyvinyl chloride),PP,PE,PVDF and etc.

Chemical Containers PVC Sheet Bending Machine 380V DVS Standard

Sheet Bending Machine Application:

Chemical Containers PVC Sheet Bending Machine 380V DVS Standard

International warranty:24months.
Any parts broken or does not work under normal operating,we are free to provide.
