The camera is tested before leaving our factory. The purpose is to ensure the quality to prevent problems from causing various troubles to both parties. We only explains the related problems of the c8051 driver. If customer chooses the mcu by themself , we do not know the hardware situation and cannot explain it!

Specification :

Pixel : 5 million

Photosensitive array : 640X480;

IO voltage : 2.5V to 3.0V (internal LDO powers the core with 1.8V);

Power consumption : 60mW/15fpsVGAYUV;

Sleep :<20μA

Operating temperature: -30℃ ~70℃

Optical Size : 1/6"

Field Angle : 25°

Frame rate 30fps VGA
Sensitivity : 1.3V/(Lux-sec);

Noise Ratio : 46 dB;

Dynamic Range : 52dB signal

Browsing mode : line by line;

Electronic exposure : from 1 line to 510 lines;

Pixel Area : 3.6μm x 3.6μm;

Dark Current : 12 mV/s at 60;

3V3-----input power supply voltage (3.3 is recommended, you can also use 5V ,but not recommended)

GDN-----Grounding point

SIO_C---SCCB interface control clock (note: some low-level MCUs require pull-up control, similar to I2C interface)

SIO_D---Serial data input (output) end of SCCB interface (Note: Some low-level MCUs need pull-up control, which is similar to I2C interface)

VSYNC---frame synchronization signal (output signal)

HREF-line synchronization signal (output signal)

PCLK-pixel clock (output signal)

D0-D7---data port (output signal)

RESTE---reset port (normal use pull high)

PWDN-power consumption selection mode (normal use pull down)

OV7670 image sensor, small size, low working voltage, provides all the functions of a single-chip VGA camera and image processor. Through SCCB bus control, it can output 8-bit impact data with various resolutions such as whole frame, sub-sampling, and windowing. The VGA image of this product reaches 30 frames per second. Users can fully control the image quality, data format and transmission method. All image processing functions including gamma curve, white balance, saturation, chroma, etc. can be programmed through the SCCB interface.

High sensitivity suitable for low illumination applications
Low voltage suitable for embedded applications
Standard SCCB interface, compatible with I2C interface
RawRGB, RGB (GRB4:2:2, RGB565/555/444), YUV (4:2:2) and YCbCr (4:2:2) output formats
Support VGA, CIF, and various sizes from CIF to 40x30
VarioPixel sub-sampling method
Automatic influence control functions include: automatic exposure control, automatic gain control, automatic white balance, automatic elimination of light streaks, automatic black level calibration. Image quality control includes color saturation, hue, gamma, sharpness ANTI_
Automatic saturation adjustment (UV adjustment)
Edge enhancement automatically adjust BLOOM
ISP has the function of noise elimination and dead pixel compensation
Support image zoom
Lens loss compensation
50/60Hz automatic detection
Automatic adjustment of noise reduction
