Galvanized / PVC Coated Wire Gabion Box Machine With Wrapped Edge Machine
Galvanized / PVC Coated Wire Gabion Box Machine With Wrapped Edge Machine
Specifications
Brand Name :
Konson
Model Number :
KS80100-4.0
Certification :
CE Certificate, ISO9001, SGS
Place of Origin :
Jiangsu, China
MOQ :
1 Set
Price :
Discuss in mail
Payment Terms :
L/C, T/T
Supply Ability :
10 Sets per Month
Delivery Time :
within 30 days in receiving prepayment
Packaging Details :
One 40' Open Top Container, wooden pallet, as your design
Warranty :
One Year
Machine type :
New
Mesh Size :
80x100mm
Wire material :
Galfan Wire
PVC wire :
Available
Color :
Customer design
Description

Gabion Machine With Wrapped Edge Machine 80x100mm For Galvanized And PVC Coated Wire Gabion Box

Konson gabion machine include four main standard parts: Main netting machine, winding machine, wire tension device and spiral coiling machine, it can produce gabions of various widths and mesh sizes. Konson gabion machine strict with CE certification has been exported to more than 40 countries before. It is our honor to provide the machine to you!

KS series machine has the feature of rational design, simple structure, smooth running, excellent performance, reliable operation and convenient maintenance.

KONSON offer better after-sale service. We can provide 12 months guarantee for all the equipments, we will arrange our engineer to install the machines in your factory and teach your workers how to produce, we will also send accessories and spare parts without any cost.

Advantages:
A1. CE certificate.
A2. QC system & timely delivery.
A3. New drive mode.
A4. Automatic oil system.
A5. Overload protect clutch.
A6. High-efficiency: theoretic output = 3.5m/min.
A7. Turbine protection system (Option).
A8. Infrared ray safety (Option).
A9. Automatic stop system (Option).
A10. All of the core parts of machines are processed by our own factory, so the quality can be ensured.

Galvanized / PVC Coated Wire Gabion Box Machine With Wrapped Edge Machine

Specification:

MODEL

MESH SIZE

MAX.WIRE DIA.

MAX WIDTH

PRODUCING RATE

KS6080-2.4

60X80

mm

3.0mm

2400mm

>3.3 m/min

KS6080-3.2

3.5mm

3200mm

KS6080-4.0

3.5mm

4300mm

KS80100-2.4

80X100

mm

3.5mm

2400mm

>3.5 m/min

KS80100-3.2

3.5mm

3200mm

KS80100-4.0

4.0mm

4300mm

KS100120-2.4

100X120

mm

3.5mm

2400mm

>3.5 m/min

KS100120-3.2

3.5mm

3200mm

KS100120-4.0

4.0mm

4300mm

KS120150-2.4

120X150

mm

4.0mm

2400mm

>3.8 m/min

KS120150-3.2

4.0mm

3200mm

KS120150-4.0

4.0mm

4300mm

Wrapped Edge Machine 80x100mm

Galvanized / PVC Coated Wire Gabion Box Machine With Wrapped Edge Machine
