Custom Welded Mesh Gabion Basket For Soil And Water Construction
Custom Welded Mesh Gabion Basket For Soil And Water Construction
Specifications
Place of Origin :
Jiangsu, China (Mainland)
Brand Name :
Konson
Model Number :
KS-Mattress
Hole Shape :
Hexagonal
Aperture :
60*80;80*100;100*120;120*150
Sotck :
We have Stock
Quality :
Superior
Price :
Discuss in mail
MOQ :
800 Square Meter/Square Meters or as your request
Port :
Shanghai
Packaging Details :
Flat bundle, binding with steel strape or strands, some rolls customer's suggestions are accepted wi
Delivery Time :
About 10 days after the deposit, according to the quantity.
Payment Terms :
L/C,D/A,D/P,T/T,or as your request
Supply Ability :
6,000 Square Meter/Square Meters per Day or as your request
Certification :
CE, ISO9001, SGS, ASTMA, EN, BS standard.
Description
Custom Welded Mesh Gabion Basket For Soil And Water Construction

Gabion Basket is a rectangular box made of galvanized double twisted hexagonal woven mesh. The compartments or cells are of equal size and its dimensions are formed by internal diaphragms placed in the box.
es
1.Galvanized, Galfan, PVC, PE
2.Various sizes can be designed
3.For soil and water construction.
4.Free sample.

Customized Hexagonal Double Twisted Gabion For Soil And Water Construction
Custom Welded Mesh Gabion Basket For Soil And Water Construction

es
It is a structure made of hexagonal double twisted wire mesh,

gabion mattresses are filled with stones at the project site to form flexible and permeable,

monolithic structures such as river bank protection and channel linings for erosion control.

Gabion mattresses are divided into uniformly partitioned cells by internal diaphragms.

Gabion Mattresses size:

Standard sizes 6x2x0.17m 6x2x0.23m 6x2x0.30m 3x2x0.17m 3x2x0.23m 3x2x0.30m

Mesh size(mm):60x80mm, 80x100mm, 100x120mm, 120x150mm

Wire diameter:2.2mm/3.2mm, 2.4mm/3.4mm, 2mm/3.0mm

We can manufacture as client's demand.

Specification:

Long(m)

Width(m)

High(m)

Mesh type(mm)

3m

2m

0.15-0.20-0.25

80x100

4m

2m

0.15-0.20-0.25

80x100

5m

2m

0.15-0.20-0.25

80x100

6m

2m

0.15-0.20-0.25

80x100

3m

2m

0.17-0.23-0.30

60x80

4m

2m

0.17-0.23-0.30

60x80

5m

2m

0.17-0.23-0.30

60x80

6m

2m

0.17-0.23-0.30

60x80

All sizes and dimensions are nominal. Tolerances of ± 3% of the width, length, and ±2.5 cm of the height shall be permitted.
