Bto-22 Coil Barbed Wire Galvanized Razor Dia 600 Mm On Ships For Anti Piracy
Bto-22 Coil Barbed Wire Galvanized Razor Dia 600 Mm On Ships For Anti Piracy
Bto-22 Coil Barbed Wire Galvanized Razor Dia 600 Mm On Ships For Anti Piracy
Bto-22 Coil Barbed Wire Galvanized Razor Dia 600 Mm On Ships For Anti Piracy
Specifications
Brand Name :
HBGB
Model Number :
BTO -10, BTO -12, BTO-18, BTO-22, CBT-60, CBT-65
Certification :
ISO 9001
Place of Origin :
China
MOQ :
50 rolls
Price :
negotiable
Payment Terms :
L/C, T/T
Supply Ability :
2000 rolls per day
Delivery Time :
10 - 20 days
Packaging Details :
1) compression rolls, 5 rolls, 10 rolls, or more rolls as one bundle 2) 1 roll, 3 rolls or 5 rolls in one carton
Product name :
Razor barbed wire
surface treatment :
hot dipped galvanized
Razor type :
cross razor type
Cover length :
8 m-15 m/coil
Razor thickness :
0.45±0.05mm
Razor barb length :
22±1mm
Inner wire diameter :
2.5±0.1mm
Razor barb width :
15±1mm
Razor barb spacing :
34±1mm
Description

BTO-22 Galvanized Razor Wire Coils Dia 600 Mm Used On Ships For Anti-Piracy

Razor barbed wire:

Razor Barbed Wire is also named concertina razor wire, razor fencing wire, razor blade wire or dannert wire. It is a kind of modern security fencing materials with better protection and fencing strength made of hot-dipped galvanized steel sheets or stainless steel sheets. With sharp blades and strong core wire, razor wire has the features of secure fencing, easy installation, age resistance and other properties.

Razor barbed wire details:

1. Material: Hot Dipped Galvanized sheet Hot Dipped Galvanized Wire / ElectroGalvanized sheet Hot Dipped Galvanized Wire
2. Core Wire Diameter: 2.7±0.1mm / 2.5±0.1mm
Razor Barbed sheet thickness: 0.45±0.05mm
3. Razor Loop Diameter: 600mm
Other Coil diameter for u choose: 300mm, 400mm, 450mm, 500mm, 600mm, 700mm, 800mm, 900mm, 1000mm.
450mm(3 clips), 500mm(3 clips), 600mm(3 clips)900mm(5 clips) are the usually sizes
4. Razor Barbed Wire per coil weight: Be produced as customers requirements. (common weight is 7KG 10KG, 12kg, 14kg)

Razor barbed wire surface treatment:


Electro galvanized core wire and blade
hot-dipped galvanized core wire and blade
stainless steel core wire and blade
PVC coated core wire and blade
Hot-dipped galvanized core wire+stainless steel blade

Razor barbed wire specifications:

Razor Wire Coil Dia. Size
Outside Diameter
No.of Loops
Standard Length per Coil
Type
Notes
450 mm
33
8m
CBT-65
Single coil
500 mm
41
10m
CBT-65
Single coil
700 mm
41
10m
CBT-65
Single coil
960 mm
53
13m
CBT-65
Single coil
500 mm
102
16m
BTO-10.15.22
Cross type
600 mm
86
14m
BTO-10.15.22
Cross type
700 mm
72
12m
BTO-10.15.22
Cross type
800 mm
64
10m
BTO-10.15.22
Cross type
960 mm
52
9m
BTO-10.15.22
Cross type

Bto-22 Coil Barbed Wire Galvanized Razor Dia 600 Mm On Ships For Anti Piracy

Packing and loading:

Bto-22 Coil Barbed Wire Galvanized Razor Dia 600 Mm On Ships For Anti Piracy
