Hot Dipped Galvanized Serrated Bar Grating Walkway Platform Webforge Steel
Hot Dipped Galvanized Serrated Bar Grating Walkway Platform Webforge Steel
Hot Dipped Galvanized Serrated Bar Grating Walkway Platform Webforge Steel
Hot Dipped Galvanized Serrated Bar Grating Walkway Platform Webforge Steel
Specifications
Brand Name :
HBGB
Model Number :
GB-006
Certification :
ISO 9001
Place of Origin :
China
MOQ :
100pcs
Price :
negotiable
Payment Terms :
L/C, T/T
Supply Ability :
2000 pcs per day
Delivery Time :
15-25 days
Packaging Details :
Steel Pallet or customized
Product namee :
Galvanized Serrated Bar Grating
Steel Grating type :
Serrated bar type
Material :
Mid steel Q235(Low carbon steel), stainless 201,304,316
Surface treatment :
hot dipped galvanized; paint; untreat
Color :
Silver
Cross Bar Size :
6 mm, 8 mm, 10 mm
Bearing bar size :
20*3mm; 25*3mm; 30*3mm; 30*5mm; 40*5mm
Cross bar spacing :
24-200 mm
Sample :
available
Alloy Or Not: :
not alloy
Description

Hot Dipped Galvanized Serrated Bar Grating Walkway Platform Webforge Steel Grating

Galvanized serrated bar grating introduction:

Steel gratings,ladders and stair treads,trench cover,handrail stanchions which are widely used in Petrochemical Industry,Oil fields,Boiling paltform,seaport and vessel construction,power plant and so on.They are very popular in Australia, South America, South-east Asia, Europe and so on.

Advantages of Galvanized serrated bar grating:

1. High strength and light structure
2. Powerful anti-corrosion, durable and long working life
3. Beautiful appearance, bright surface
4. No dirt-rain-snow deposit, automatic cleaning, easy maintenance
5. Good ventilation, day-lighting, heat-dispersing, resistant to sliding and explosion.
6. Easy installation

Galvanized serrated bar grating surface treatment:

Untreated, Painting or Hot Dipped Galvanizing

Galvanized serrated bar grating surface specifications​:

Product name *Steel grating
Material

*Mild steel (Carbon steel)

*stainless steel 304, SS316
Material standard

*USA:ASTM A36

*UK:BS4360

*Australia:AS3679

*China:Q235
Bearing bar type

*Smooth/flat bar

*serrated/toothed bar

*Smooth I bar

*Serrated I bar
Bearing bar thickness *2mm to 10mm, 3mm and 5mm recommended
Bearing bar pitch *12.5-30mm/40mm/50mm/60mm/80mm/90up,30and40mm recommended
Bearing bar specification

*flat bar and serrated bar 20*3,20*5,25*3,25*5,30*3,30*4,30*5,32*3,32*5,35*3,35*5,40*3,40*5,

45*5,50*3,50*5,55*5,60*5,65*5,70*6,75*6,75*8,80*8,90*8,100*8,

120*8,130*8,150*8

*I-section bar 25*5*3,32*5*3,38*5*3,44*5*3,50*5*3,50*7*4,55*7*4,60*7*4,

65*7*4,75*7*4
Cross bar *5*5mm,6*6mm,8*8mm
Cross bar pitch *30mm,38mm,50mm,76mm,100mm,50mm and 100mm recommended
Surface treatment

*Hot dipped galvanized

*Untreated(self-color)

*Painted
HDG standard

*ASTM A123

*BS729

*AS1650
Grating Standard

*AS1657-2013

*BS4592-2006

*ANSI/NAAMM(MBG531-88)

Product pictures:

Hot Dipped Galvanized Serrated Bar Grating Walkway Platform Webforge Steel

Applications of galvanized serrated steel bar grating:

* Anti slip bridge decking
* Bridge walkway
* Drainage systems
* Fire truck platforms
* Mass transit platforms
* Marine and ship decks
* Mezzanines
* Non-slip walkways
* Non-skid pit covers
* Slip resistant platforms
* General Industries
* Truck platforms
* Vault covers
* Wet Decks
* Wastewater treatment plant grating
* Stair treads


Hot Dipped Galvanized Serrated Bar Grating Walkway Platform Webforge Steel
