Hexagonal Hole Weaving Type Gabion Wire Baskets 60 X 80mm For Retaining Wall Construction
Hexagonal Hole Weaving Type Gabion Wire Baskets 60 X 80mm For Retaining Wall Construction
Hexagonal Hole Weaving Type Gabion Wire Baskets 60 X 80mm For Retaining Wall Construction
Hexagonal Hole Weaving Type Gabion Wire Baskets 60 X 80mm For Retaining Wall Construction
Specifications
Brand Name :
HBGB
Model Number :
GB-002
Certification :
ISO 9001
Place of Origin :
China
MOQ :
100PCS
Price :
negotiable
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
1000 pcs per day
Delivery Time :
10-25days
Packaging Details :
compacted before packaging, in bundle
Product name :
Gabion mattress/gabion basket
Raw Material :
pvc coated wire, galvanized wire
Net wire diameter :
2.7mm
mattress height :
0.3 m or 0.5m standard
gabion basket height :
1 m standard
basket width :
1m
Length :
2-6m
Mesh size :
60 x 80 mm; 80 x 100 mm;100 x 120 mm;120 x 150 mm
Usage :
gabion mattress for fiver band and slope protection
Factory location :
Hebei, China
Description

Hexagonal Hope Weaving Type Gabion Mesh Basket For Retaining Wall Construction

Green Gabion Mattress Introduction:

Gabion net is made of low carbon steel wire with high corrosion resistance, high strength and ductility or PVC coated steel wire by mechanical weaving. The box structure made of the net is gabion net,net is used for the scour protection of rivers, dikes and seawalls, as well as cage for the closure of reservoirs and rivers. The most serious disaster of the river is that the water scours the Bank of the river and causes the flood, which leads to a lot of loss of life and property and a lot of soil erosion. Therefore, when dealing with the above problems, the application of the grid ecological grid structure becomes one of the best solutions, which can make the river bed and bank permanent protection.

Gabion basket Characteristics:

1. economy. Just put the stone into the cage and seal it.
2. The construction is simple without special technology.
3. It has a strong ability to resist natural damage, corrosion resistance and adverse climate impact.
4. It can withstand large-scale deformation without collapse.
5. The silt between the stone gaps of the cage is conducive to plant production and can be melted into one with the surrounding natural environment.
6. It has good permeability and can prevent damage caused by hydrostatic force. Conducive to the stability of hillside and beach
7. Save transportation cost, fold it up for transportation and assemble it on the construction site. 8. Good flexibility: no structural joint, the overall structure has ductility.
9. Corrosion resistance : galvanized materials are not afraid of seawater.
10. Environmental protection materials: cadmium (CD) < 10ppm, lead (PB) < 50ppm,
other harmful substances such as mercury (Hg), hexavalent chromium (Cr6 +), PBB and PBDE are not detected, which fully meet the environmental protection standards of Rosh.

Gabion Specifications:

Specifications of gabion mattress
Length
(m)		 Width
(m)		 Height
(m)
2 1 0.15
0.17
0.23
0.3
3 1
3 2
4 1
4 2
5 1
5 2
6 1
6 2

Hot dip galvanized gabion box
Size(m) Mesh size(cm)

Diameter(mm)

selvage wire/mesh wire/tie wire

2x1x1

2x1x0.5

8x10

10x12

3.4/2.7/2.2

3.9/3.0/2.2

3.9/2.7/2.2

3x1x1

3x1x0.5
4x1x1

PVC coated gabion box
Size(m) Mesh size(cm)

Before PVC Diameter(mm)

selvage wire/mesh wire/tie wire

After PVC Diameter(mm)

selvage wire/main wire/tie wire

2x1x1

2x1x0.5

8x10

10x12

 3.4/2.7/2.2 4.4/3.7/3.2

Hexagonal Hole Weaving Type Gabion Wire Baskets 60 X 80mm For Retaining Wall Construction

Packing and transportion:

Hexagonal Hole Weaving Type Gabion Wire Baskets 60 X 80mm For Retaining Wall Construction

Applications:

Control and guide of water or flood
Flood bank or guiding bank
Preventing of rock breaking
Water and soil protection
Bridge protection
Strengthening structure of soil
Protection engineering of seaside area

Hexagonal Hole Weaving Type Gabion Wire Baskets 60 X 80mm For Retaining Wall Construction
