2mm Hex 1x1x0.5m Galvanised Steel Gabion Cages For Dam Protection
2mm Hex 1x1x0.5m Galvanised Steel Gabion Cages For Dam Protection
2mm Hex 1x1x0.5m Galvanised Steel Gabion Cages For Dam Protection
2mm Hex 1x1x0.5m Galvanised Steel Gabion Cages For Dam Protection
Specifications
Brand Name :
HBGB
Model Number :
GB-002
Certification :
ISO 9001
Place of Origin :
China
MOQ :
50 PCS
Price :
negotiable
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
1000 pcs per day
Delivery Time :
10-25days
Packaging Details :
compacted before packaging, in bundle
Product name :
Gabion Mesh basket
Material :
iron wire Q195
Surface treatment :
galvanized, galfan, plastic coated
Wire diameter :
popular 2.7mm (2.0-4.0mm)
Hole shape :
hexagonal
Aperture :
8 x 10 cm (standard)
Usage :
dam, bank, river, slope protective mesh
Sample :
sample for free; shipping cost paid by customers
Packing :
compressed by machine and in bundle
If factory :
yes
Description

Easy assembled steel wire weaving Gabion mesh basket for dam protection

Gabion Mesh Basket Introduction:

Gabion Mesh is also called Product Name: Gabion Box,Gabion Basket, Stone Cage, , Hexagonal Wire Mesh, Gabion Mesh, PVC Coated Gabion Box, Galfan Gabion Basket, Stone Gabion, Gabion Cage, Gabion Retaining Wall.

Gabion baskets are made of heavy galvanized wire / ZnAl (Golfan) coated wire / PVC or PE coated wires, the mesh shape is hexagonal style. The gabion baskets are used widely in slope protection, foundation pit supporting, mountain rock holding, river and dams scour protection

Gabion Mesh Basket Details:

Gabion Wire Materials: Quality Galvanized Wire, Galfan Wire etc.
Gabion Basket sizes: 1x1x0.5m,1x1x1m, 2x1x0.5m, 2x1x1m, 3x1x1m, 3x1x0.5m, 4x1x0.5m, 4x1x1m, 6x2x0.3m,Custom orders available.
Gabion Mesh Size:60*80mm, 80*100mm,100*120mm, 120*150mmCustom orders available.
Gabion basket surface Treatment: Finish can be hot-dipped galvanized, galvanized aluminum alloy or PVC coated, etc.

Gabion Mesh Basket Applications:

1.Controlling and leading the river and flood.
2. Flood discharge and lead flow.
3. Rock fall defending.
4. Preventing the water and soil lost.
5. Protecting the bridge.
6. Reinforce fabric.
7. Seashore recovery project.
8. Seaport project.

Gabion Mesh Basket Specifications:

Mesh size and wire thickness
Gabion Boxes
80x100mm
100x120mm
Mesh Wire Dia.
2.70mm
Zinc coating: >260g/m2
Edge Wire Dia.
3.40mm
Zinc coating: >275g/m2
Tie Wire Dia.
2.20mm
Zinc coating: >240g/m2
Mattress
60x80mm
Mesh Wire Dia.
2.20mm
Zinc coating: >240g/m2
Edge Wire Dia.
2.70mm
Zinc coating: >260g/m2
Tie Wire Dia.
2.20mm
Zinc coating: >240g/m2
Special sizes are available.
Mesh Wire Dia.
2.00~4.00mm
Edge Wire Dia.
2.70~4.00mm
Tie Wire Dia.
2.00~2.20mm

Normal box size

(m)

Mesh size

(mm)

No. of diaphragms

(no.)

Capacity per box

(m3)

1.0x1.0x0.5

50x50

75x75

50x100

100x100

0

0.50

1.0x1.0x1.0

0

1.00

1.5x1.0x0.5

0

0.75

1.5x1.0x1.0

0

1.50

2.0x1.0x0.5

1

1.00

2.0x1.0x1.0

1

2.00

3.0x1.0x0.5

2

1.50

3.0x1.0x1.0

2

3.00

4.0x1.0x0.5

3

2.00

4.0x1.0x1.0

3

4.00

Woven type Gabion mesh basket:

2mm Hex 1x1x0.5m Galvanised Steel Gabion Cages For Dam Protection

Application:

2mm Hex 1x1x0.5m Galvanised Steel Gabion Cages For Dam Protection

Loading:

2mm Hex 1x1x0.5m Galvanised Steel Gabion Cages For Dam Protection
