Rock Filled 2.7mm Hexagonal Wire Mesh For Retaining Wall
Rock Filled 2.7mm Hexagonal Wire Mesh For Retaining Wall
Rock Filled 2.7mm Hexagonal Wire Mesh For Retaining Wall
Rock Filled 2.7mm Hexagonal Wire Mesh For Retaining Wall
Specifications
Brand Name :
Zhuoda
Model Number :
ZD-04
Certification :
ISO9001
Place of Origin :
Anping China
MOQ :
100 Sets
Payment Terms :
T/T, L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability :
10000 Sets
Delivery Time :
5-7days
Packaging Details :
By Pallets
Model number :
Gabion Hexagonal Mesh
Material :
PVC Coated Wire, Galvanized wire
Process :
Weaving Mesh
Application :
Roadway Protection, River Control
Hole Shape :
Hexagonal Mesh
Wire Gauge :
2.0mm, 2.7mm, 3mm 3.5mm 4mm
Surface Treatment :
Hot Dipped Galvanized
Zinc Coated :
220-270g
Gabion Size :
2x1x1,3x1x1,4x1x1,6x2x0.3
Mesh Size :
60x80 80x100 80x120 100x120
Description

3x2x0.17m 2.7mm Gabion Retaining Wall Rock Filled Gabion Wire Baskets Hexagonal Wire Mesh


Hexagonal Wire Mesh introduction:

Gabion Wire Baskets are wire containers made of hexagonal wire netting.wire diameter varies with the hexagonal nettings.for hexagonal wire netting without pvc coating,the wire diameter ranges from 2.0mm to 4.0mm.for those PVC coated hexagonal wire netting,the outside diameter ranges from 3.0mm to 4.5mm.The wire of the outside frame edga is one wire gauge thicker than the wire used for hexagonal wire netting.

1.Material:Hot dip galvanizedwire,PVC coated wir,eGalfan-coated wire
2.Type:Double twisted hexagonal

3.Surface treatment:Hot dipped galvanized ,electric galvanized and pvc coated.

4.Weaving character:Normal twisted, reverse twisted and double-way twisted.


Hexagonal Wire Mesh Specification:

Material Galvanized wire


Surface treatment

 Hot dipped galvanized (Zinc Coated)
Galfan coated: 95% Zinc + 5% Aluminum, 90%Zinc +10% Aluminum
Zinc(galvanized) + PVC Coated (Gray or Green)

Gabion Basket/Gabion Box/Gabion Mesh/Gabion Cage Specification
Wire diameter 2.0-4.0mm
Mesh opening 80 x 100mm 90 x 110mm 100 x 120mm 60 x 80mm etc.
Dimension 1x0.5x0.5m, 1x1x1m, 2x1x0.5m, 2x1x1m, 3x1x0.5m, 3x2x0.3m, 3x2x0.17m, 3x1x1m, 4x1x0.5m, 4x1x1m, 4x2x0.3m, 5x1x1m, 5x1x0.5m,
6x2x0.3m or as request

Material galvanzied wire
Wire diameter 2.0-4.0mm
Mesh Size 60*80mm, 80*100mm, 80*120mm, 100*120mm, 100*150mm, 120*150mm
Surface treatment hot-dipped galvanzied/PVC coated
Color silver/green/black green
Application soil, bridge construction, water bank

Specifications offered
Length Width Height Diaphragm CUM The tolerance
M M M Unit M3
2 1 0.3 1 0.6
3 1 0.3 2 0.9
4 1 0.3 3 1.2 length+-3%
2 1 0.5 1 1 width+-5%
3 1 0.5 2 1.5 height+-5%
4 1 0.5 3 2
1 1 0.5 0 1 Hole size
1.5 1 1 0 1.5 60x80mm
2 1 1 1 2 80x100mm
3 1 1 2 3 100x120mm
4 1 1 3 4

Hexagonal Wire Mesh advantages:


Gabion mesh or Gabion Wire Baskets has some obvious advantages ,such as corrosion prevention ,eletrostatic prevention ,age resistance ,corrosion-resistance ,compressive resistance ,sheaving resistance and improving the protective function in the highly polluted environment.This kind of mesh mainly used in river,sea and highly polluted area.

Hexagonal Wire Mesh Application:

a. Control and guide of water or flood
b. Prevent of rock breaking
c. Protect rock fall
d. Protect Water and soil protection
e. Protect bridge
f. Strengthen structure of soil
g. Protect engineering of seaside area.
h. Build Port project
i. Keep off dust wall
j. Protect roadway

Hexagonal Wire Mesh Package:

1. compacted before packaging.
2. Plastic packaging outside and on the pallet.
3. 20'container can contain more than 8,000 square meters.
40' container can contain more than 15,000 square meters

Rock Filled 2.7mm Hexagonal Wire Mesh For Retaining WallRock Filled 2.7mm Hexagonal Wire Mesh For Retaining WallRock Filled 2.7mm Hexagonal Wire Mesh For Retaining Wall
