Pure Water 5 Gallon Bottle Barrel Filling Machine 600BPH / 900BPH Water Production Line
Pure Water 5 Gallon Bottle Barrel Filling Machine 600BPH / 900BPH Water Production Line
Pure Water 5 Gallon Bottle Barrel Filling Machine 600BPH / 900BPH Water Production Line
Pure Water 5 Gallon Bottle Barrel Filling Machine 600BPH / 900BPH Water Production Line
Pure Water 5 Gallon Bottle Barrel Filling Machine 600BPH / 900BPH Water Production Line
Pure Water 5 Gallon Bottle Barrel Filling Machine 600BPH / 900BPH Water Production Line
Pure Water 5 Gallon Bottle Barrel Filling Machine 600BPH / 900BPH Water Production Line
Pure Water 5 Gallon Bottle Barrel Filling Machine 600BPH / 900BPH Water Production Line
Pure Water 5 Gallon Bottle Barrel Filling Machine 600BPH / 900BPH Water Production Line
Pure Water 5 Gallon Bottle Barrel Filling Machine 600BPH / 900BPH Water Production Line
Specifications
Brand Name :
Fillpack
Model Number :
QGF-450,QGF-300,QGF-600,QGF-900
Certification :
CE/ISO9001
Place of Origin :
Zhangjiagang, China
MOQ :
1 set
Price :
10575USD-30228USD
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
20Sets per month
Delivery Time :
25-30 Working days
Packaging Details :
Wooden case
Capacity :
300-900BPH
Volume :
18.9L/3-5 Gallon
Barrel size :
D270*490 mm
Filling Heads :
1-6
Gas pressure :
0,4-0.6 Mpa
Voltage :
380V 50Hz
Material :
SUS 304
Power :
1.38-21.55KW
Description

300BPH / 450BPH / 600BPH / 900BPH Pure Water 5 Gallon Bottle Barrel Bucket Jar Filling Machine / Equipment Water Production Line

*We supply complete solution for the 5 gallon bucket filling machine ,including Water treatment system / Decapping machine /Inside brusher / Externer brusher / Automatic 5 Gallon rinsing filling capping machine / Automatic Cap sleeve label machine / Code sprayer / Film wrapping machine / Automatic 5 gallon palletizer system

This production line is an automatic barrel production line for drinking water of 3-5gallon. Meanwhile, it is also suitable to produce barrel wine, vinegar, medicine and so on. This production line is adopted sufficiently tech-knowledge from overseas’ drinking water equipment and plus our elaborately design due to our nation tradition to work out. So it has full functions, low energy consumption, low investment, and higher and fast effecting characteristic.
The main electrical elements adopt the products with brands of SIEMENS and OMRON. Pneumatic elements adopt the products with brand of AIRTAC. This production line is adopted sufficiently tech-knowledge from overseas’ drinking water equipment and plus our elaborately design due to our nation tradition to work out. So it has full functions, low energy consumption, low investment, and higher and fast effecting characteristic. The main electrical elements adopt the products with brands of SIEMENS and OMRON. Pneumatic elements adopt the products with brand of AIRTAC.

Technical parameter : water filling machine
Model
QGF-300
QGF-450
QGF-600
QGF-900
Capacity(for 5 gallon)
300bph
450bph
600bph
900bph
Suitable bottle shapes
PET circular or square
Bottle volume
3 & 5 Gallon
Air consumption
0.4-0.6 m3/min
Rinsing pressure
>0.06Mpa <0.2Mpa
Application
5 gallon water production plant
Total power (KW)
3.8kw
3.8kw
6.5kw
9.5kw
Overall dimensions
3000*1700*1750
5000*2000*1800
5000*2300*1800
5200*2300*2200
Weight(kg)
1500kg
2100kg
3000kg
3500kg

Pure Water 5 Gallon Bottle Barrel Filling Machine 600BPH / 900BPH Water Production LinePure Water 5 Gallon Bottle Barrel Filling Machine 600BPH / 900BPH Water Production Line
