Mechanical Driven 600BPH 5 Gallon Water Bottling Machine
Mechanical Driven 600BPH 5 Gallon Water Bottling Machine
Mechanical Driven 600BPH 5 Gallon Water Bottling Machine
Mechanical Driven 600BPH 5 Gallon Water Bottling Machine
Mechanical Driven 600BPH 5 Gallon Water Bottling Machine
Mechanical Driven 600BPH 5 Gallon Water Bottling Machine
Mechanical Driven 600BPH 5 Gallon Water Bottling Machine
Mechanical Driven 600BPH 5 Gallon Water Bottling Machine
Specifications
Brand Name :
FILL PACK
Model Number :
QGF600
Certification :
CE, ISO9001
Place of Origin :
ZhangJiaGang JiangSu China
MOQ :
1 set
Price :
USD $18,000-$20,000/set
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
5 sets/month
Delivery Time :
15-20 working days
Packaging Details :
wooden case
bottle size :
10~20 L PET round bottle
capacity :
600BPH
Driven Type :
Mechanical
Voltage :
380V 50HZ 3P or customized
Dimension(L*W*H) :
5000*2300*1800mm
Machine type :
Linear type
Product :
drinking water
Max filling volume :
5 gallon /18.9L
Description

Description of Automatic gallon water bottling line for 5 Gallon Bottle with 600BPH

600 B/h (5gallon) gallon water bottling line
Output:600B/H(5 gallon /18.9L)
Product: drinking water
Model of equipment:QGF-600
Suitable of barrel::5 gallon barrel (Ф270×490×Ф56)
Max filling volume:5 gallon /18.9L
capper:5gallon clear capper(Ф56×39+17×8)
Filling fashion:pressure filling
Transportation fashion:motor drive transportation

The flow of the whole gallon water bottling line:

5 gallon barrel
↓
Auto lid pulling out machine
↓
Auto exterior brushing machine
↓
Auto loading barrel system
↓
Disinfection and washing→full auto filling, capping system←water treatment, original water
↓
Inspection light
↓
Heat shrinking machine
↓
Ink jet printer
↓
conveying system

1, Automatic De-capper:
De-capping head: 2 heads
Dimension: 900*600*2000mm
Weight: 130kg

2, Rotary external washer

Dimension: 1800*1550*1750mm

Weight: 800kg

Power: pump 0.37+motors 0.75*2+transfer motor 1.1=2.97KW

Recycle water tank size: 600*550*550mm

3, Monoblock gallon rinser-filler-capper

Material: SUS304

Power:22KW

Dimension: 5000*2300*1800mm

Weight: 1000kg

We aslo have other capacities of gallon water bottling line:

Model QGF-100 QGF-200 QGF-300 QGF-450 QGF-600 QGF-900 QGF-1200
Filling heads 1 2 2 3 4 6 12
Volume 3&5 Gallon
Barrel size Φ270*490mm
Capacity(b/h) 60-100 100-240 250-300 400-450 600-800 800-900 1000-1200
Air pressure(MPa) 0.4-0.6 0.4-0.6 0.4-0.6 0.4-0.6 0.6 0.6 0.6
Air consumption(m³/min) 0.37 0.37 0.6 0.8 1 1.5 1.8
Motor power(kw) 1.38 1.75 3.8 3.8 7.5 9.75 13.5
Rated power(kw) 1.38 1.75 3.8 3.8 7.5 9.75 13.5

4, Steam shrink Machine
5, Ink jet code printer

1 bottle of ink for 2mm: 20 million characters;

If you print one line 8 characters each bottle, then 1 bottle of ink can last around 5 month; If extra needed, unit price: 55USD/bottle;

6, Automatic cap lifter-washer

The Automatic cap elevator is designed to lift bottles caps to capping machine, which there is a cap sorting machine before capping. It is not only used in beverage industry, also can be used in food, hardware, packaging, medical and chemical industry.

Detailed pictures of gallon water bottling line:

The 4 filling heads

Mechanical Driven 600BPH 5 Gallon Water Bottling Machine

The Ink jet code printer

Mechanical Driven 600BPH 5 Gallon Water Bottling Machine

After service:
1. We send the engineers to help installing, commissioning and training, the engineers start from our factory area.
2. We supply below necessary documents with the machine:
a. Machine layout
b. Electricity diagram
c. Machine certificate
d. General manual book/maintenance book
3. After one year guarantee, the seller provides payable spare parts and technician’s VISITING maintenance

service.
