Mechanical Machine Galvanized Hex Nut M24 Size White Color High Strength
Mechanical Machine Galvanized Hex Nut M24 Size White Color High Strength
Mechanical Machine Galvanized Hex Nut M24 Size White Color High Strength
Mechanical Machine Galvanized Hex Nut M24 Size White Color High Strength
Specifications
Brand Name :
MAIDE
Model Number :
M6-M30
Certification :
ISO
Place of Origin :
Yongnian，Hebei,China
MOQ :
1 TON
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Delivery Time :
20-30 days
Packaging Details :
Bag+Wooden Pallets
Color :
Yellow & White & Black
Size: :
M16，M18
Grade :
4.8
Standard :
ISO4775
Material :
Iron
Description

Mechanical Machine Galvanized Hex Nut M24 Size White Color With High Strength

Product Description

Hex nuts are bolts or bolts screwed together for fastening parts,An element that must be used in all manufacturing machinery.According to the main attributes of the Chinese standard (GB),German standard (DIN),International Standard (ISO),Japanese standard (JIS),American Standard (ASTM / ANSI)Other standards.The Chinese standard,German standard,Japanese standardWith M said(Eg M8,M16),American Standard,British standard points or # said specifications (such as 8 #,10 #,1 / 4,3 / 8).

The hexagon nut is one of the commonly used nuts.Nuts are divided into common nuts and high strength nuts.

Grade 8 ISO 4775 High Strength Steel Hex Nut M24 White Color And Zinc Plated,it is high strength,the grade is 8,the standard is ISO 4775,the size is M24,the surface treatment is white zinc plated.This is one of the main products of our company.

Our company can produce all kinds of standard products, including:DIN,GB,JIS,ANSI,ASTM,ISO,etc.The size of our hex nuts is from M5 to M64.We use the material is carbon steel(Q235,Q195),stainless steel(A2 or A4),and alloy steel(35#,45#,40cr ect).The surface treatment of our company's hex nut have plain,black oxide,zinc plated(white,yellow,blue),hot galvanized and polishing.The hexagon nut is widely used and is very tight and the fastening force is relatively large.

Dear old and new customers, welcome to our company to purchase, we will provide you with a dragon service, from pre-sale to after-sale, we will have a good communication.We can provide free samples for you to check the quality of our products.

Product parameters
Thread
Specifications		 To The Margin(MM) Height H(MM) Circumference Diameter Every 1000/KG
Nominal Size Tolerance Nominal Size Tolerance
M1.6 3.2 -0.16 1.3 ±0.2 3.7 0.075
M2 4 1.6 4.6 0.119
M2.5 5 2 5.8 0.22
M3 5.5 2.4 6.3 0.393
M4 7 -0.2 3.2 ±0.24 8.1 0.844
M5 8 4 9.2 1.24
M6 10 5 11.5 2.317
M8 14 -0.24 6 16.2 5.674
M10 17 8 ±0.29 19.6 10.99
M12 19 -0.28 10 21.9 16.32
M14 22 11 ±0.35 25.4 25.28
M16 24 13 27.7 34.12
M18 27 14 31.2 44.19
M20 30 -0.34 16 34.6 61.91
M22 32 18 36.9 75.94
M24 36 19 ±0.5 41.4 111.9
M27 41 22 47.3 168
M30 46 -0.4 24 53.1 234.2
M36 55 28 63.5 370.9
M42 65 32 75 598.6
M48 75 38 86.5 957.3



Applications

Automotive industry, machinery manufacturing, pneumatic tools, furniture hardware, construction and so on.

Features
Wide range of applications, characterized by a larger fastening force, the disadvantage is that there must be sufficient space for installation, the installation can be used to live wrenches, open-end wrenches or glasses wrenches, the above wrenches require a lot of space for operation.
