Anti Corrosion Galvanized Steel Angle High Mechanical Strength Painted Surface
Anti Corrosion Galvanized Steel Angle High Mechanical Strength Painted Surface
Anti Corrosion Galvanized Steel Angle High Mechanical Strength Painted Surface
Anti Corrosion Galvanized Steel Angle High Mechanical Strength Painted Surface
Specifications
Brand Name :
T&T
Model Number :
EQUAL
Certification :
ISO
Place of Origin :
CHINA
MOQ :
ONE BUNDLE
Price :
USD$630-720/TON
Payment Terms :
L/C, T/T
Supply Ability :
10000TON PER MONTH
Delivery Time :
5-8 DAYS
Packaging Details :
Nude packing/Canvas packing/Bundles packig
Surface treatment :
Hot Dip Galvanised
Technique :
Hot Rollled
Dimensions :
20*20*3mm-200*200*24mm
Length :
6m 9m 12m(OR Cut)
Material :
Q235/Q235B/Q345/Q345B/SS400
Package :
Standard Sea-worthy Packing,Packing in bundle with steel strips,in bundle or as your requirements
Product name :
equal Angle Bars/MS Angle/Galvanized angle steel
Keywords :
Angel Steel Bar,slotted angle bar,hot dip galvanized angle steel
Sample :
Sample Free
Shipment :
Container Basis FCL or LCL,Container or in bulk
Deep Process :
Punched
Description

Galvanized Steel Angle Shelf Produce Equal Slotted Steel Angle Angle Galvanized Steel

T&T as a manufacturer and trade company, which is producing steel pipe for many years in Tianjin, China. Depends on more than 10 years export experiences, our professional team have won the market all over the world based on high quality products, reasonable price, excellent service and honest business. Our main products are kinds of steel pipe (ERW/SSAW/LSAW/Seamless), beam steel (H Beam/U Beam, etc), steel bar (Angle bar/Flat bar/Deformed rebar, etc),CRC &HRC, GI, GL &PPGI, sheet and coil, scaffolding, steel wire, wire mesh, etc.

Our company aim is to provide high quality pipes with moderate price and fast delivery to our dear clients. One time deal is not what we are looking for. With nearly 10 years experience in steel pipes, we have clients from Europe, Mideast and Southeast. And most of our clients have cooperated with us for more than 5 years, some even above 10 years.

Quick Details of Galvanized Steel Angle:

Slotted Angle Iron Shelving/shelf

Facially slotted angle racking system is an all-purpose framing system, roll formed from high strength steel strips. It is designed to be used as
economical shelving, racks or electrical and mechanical supports. The unique pattern of horizontal and vertical slots permits
full flexibility. Three basic sizes are available for light, medium, and heavy duty applications.

Lengths: According to customized size

Features

1).Double-layer angle post or single angle post could be chosen;

2).Z-beam or Step-beam could be matched;

3).Steel shelving or wooden panel, footplate and other accessories;

4).Easy to install and disassemble;

5).Surface treatment: powder painting;

6).Packing: Neutral paper box or in bulk or upon clients requirements
Type Equal Steel Angle Iron

Product name SPEC (mm) Thickness (mm) Length Capacity (lbs)
Angle post (Equilateral) 32*32 35*35 36*36 37*37 38*38 40*40 1.2-2.0 H24”-144” 1000-3000
Angle post (Inequilateral) 60*40 57*37 1.5-2.0 H60”-192” 1500-3500
Shelves (without supporter) 900*300/400/450/600 0.7-1.0 100-200
Shelves (with supporter) 900*300/400/450/600 0.7-1.0 150-350
Corner plate 70*70 0.7
Bolts &nuts M8*16
Base plate 0.5 0.6 1.0 1.2


Specification list:

EQUAL ANGLE STEEL GB/T9787-1988 GB/T706-2008
NO Dimension(mm) W*W*T Theoretical Weight (kg/m) NO Dimension(mm) W*W*T Theoretical Weight (kg/m)
1 25×25×3 1.124
2 25×25×4 1.459
3 30×30×3 1.373
4 30×30×4 1.786
5 40×40×3 1.852
6 40×40×4 2.422
7 40×40×5 2.976
8 50×50×3 2.332
9 50×50×4 3.059
10 50×50×5 3.77 38 100×100×14 20.611
11 50×50×6 4.465 39 100×100×16 23.257
12 60×60×5 4.57 40 110×110×7 11.928
13 60×60×6 5.4 41 110×110×8 13.532
14 63×63×4 3.907 42 110×110×10 16.69
15 63×63×5 4.822 43 110×110×12 19.782
16 63×63×6 5.721 44 110×110×14 22.809
17 63×63×8 7.469 45 125×125×8 15.504
18 70×70×5 5.397 46 125×125×10 19.133
19 70×70×6 6.406 47 125×125×12 22.696
20 70×70×7 7.398 48 125×125×14 26.193
21 70×70×8 8.373 49 140×140×10 21.488
22 75×75×5 5.818 50 140×140×12 25.522
23 75×75×6 6.905 51 140×140×14 29.49
24 75×75×7 7.976 52 140×140×16 33.393
25 75×75×8 9.03 53 160×160×10 24.729
26 70×75×10 11.089 54 160×160×12 29.391
27 80×80×6 7.376 55 160×160×14 33.987
28 80×80×8 9.658 56 160×160×16 38.518
29 80×80×10 11.874 57 180×180×12 33.159
30 90×90×8 10.946 58 180×180×14 33.383
31 90×90×10 13.476 59 180×180×16 44.542
32 90×90×12 15.94 60 180×180×18 48.634
33 100×100×6 90366 61 200×200×14 42.894
34 100×100×7 10.83 62 200×200×16 48.68
35 100×100×8 12.276 63 200×200×18 54.401
36 100×100×10 15.12 64 200×200×20 60.056
37 100×100×12 17.898 65 200×200×24 71.168

Chemical Composition:

Elements
Material		 Chemical Composition% Mechanical Property
C% Mn% S% P% Si% Yield Point (Mpa) Tensile Strength(Mpa) Elongation
(%)
Q195 0.06-0.12 0.25-0.50 <0.050 <0.045 <0.30 >195 315-430 32-33
Q215 0.09-0.15 0.25-0.55 <0.05 <0.045 <0.30 >215 335-450 26-31
Q235 0.12-0.20 0.30-0.70 <0.045 <0.045 <0.30 >235 375-500 24-26
Q345 <0.20 1.0-1.6 <0.040 <0.040 <0.55 >345 470-630 21-22

Payment Terms T/T, L/C, Western Union, Trade Assurance, Cash or as required
Price Terms FOB, CRF, CIF, EXW
Delivery Time Generally it is 5-10 days if the goods are in stock. or it is 30 days if the goods are not in stock, it is according to quantity.
Packing steel wire bundle or as costumer requirement.
Shipping Details

LCL

FCL

Bulk Shipment
Container Info

20ft GP: L5.8m * W2.13m * H2.18m , about 27 CBM, Loading Max.27 Tons

40ft GP: L11.8m * W2.13m * H2.18m, about 54 CBM, Loading Max.27 Tons

40ft HG: L11.8m * W2.13m * H2.72m, about 68 CBM, Loading Max.27 Tons

Field of use and application:

Steel structure;

Crash barrier,

Stand post;

Fence post

FAQ

Q: Are you trading company or manufacturer ?

A: We are agent of factory.

Q: How long is your delivery time?

A: 10-15 days after received your deposit or original L/C .

Q: Do you provide samples ?is it free or extra ?

A: Yes, we could offer the sample for free charge but do not pay the cost of freight.

Q: What is your terms of payment ?

A: T/T,100% L/C at sight, Cash, Western Union.
