Galvanised J / M Steel Grating Clips Fastener Stainless Steel Surface
Galvanised J / M Steel Grating Clips Fastener Stainless Steel Surface
Galvanised J / M Steel Grating Clips Fastener Stainless Steel Surface
Galvanised J / M Steel Grating Clips Fastener Stainless Steel Surface
Specifications
Model Number :
steel grating clamps
Certification :
sgs
MOQ :
1
Price :
FOB 0.3 USD/PIECE
Payment Terms :
L/C, T/T
Supply Ability :
20000 per month
Delivery Time :
20 days
Packaging Details :
naked or wooden package .
Place of Origin: :
Hebei, China (Mainland)
Model Number: :
stainless Steel grating clamps
Material: :
Iron,Stainless Steel
type: :
“J” Clips “M” Clips (saddle clips)
C-B: :
30mm
thickness: :
5mm and 6mm
surface: :
stainless steel
production time: :
10 days
Description

Galvanised steel grating clips fastener Stainless Steel Grating Clips

Stai Stainless Steel Grating Clips & Fasteners

  • “J” Clips
    - Hold a single bar and are nearly the same height as the grating
    - These clips can be pulled down completely to the support under the grating
    - Grating Thicknesses 5/8” 1” 1 ½” and 2”
  • “M” Clips (saddle clips)
    - Hold two bars and can be used to snug the grating to the support.
    - For Molded bar spacing @ 1” 1 ½”narrow 1 ½”wide and 2”
    - Clips for Pultruded Grating thicknesses from 1” 1 ½ “ and 2”
  • EPC (end panel clips)
    - Used to hold two separate pieces of grating, or two separate panels of grating
    - These should be used where a grating seam crosses a walking path and there is no support immediately under that seam
    - EPC Clips are offered for grating thicknesses of: 1”, 1 ½”, and 2”

Application: Attaches grating to structure

Contract Catalog Item:Y

Distance Between Grating Bars:1-1/2"

Expanded Catalog Item:Y

Finish:Galvanized or stainless steel

Grating Bar Depth:2-3/4"

Grating Bar Width:7/8"

Material:Steel

Model Compatibility:Bar Grating, 1-3/16" on Center, 1-1/2" Tall

Style:Mechanical Clamp

Type:Grating G-Clip

Product Weight:9 lbs.

Applications:Attaches Grating to Structure

Notes:Quick Install, Work Done Above Grating, No Damage to Structures

Types of fixing clips:

* Type A - comprising a top clip with double saddle, a lower clip with teeth and a M10 (or M8)
* Type B - comprising a top clip with double saddle (of which one saddle can secure the two bearing bars of adjacent panels), a lower clip with teeth and a M10 (or M8)
* Type C - comprising a top clip with double saddle and a M10 (or M8)

Galvanised J / M Steel Grating Clips Fastener Stainless Steel Surface

product code screw dia (mm) grating width (mm) grating depth (mm)
min max max
GRAT 1G08 M08 30 41 50

Technical Data

product code material/finish screw
dia		 body
width (mm)		 tightening
torque (Nm)
GF3 S08 ASSY 304 stainless steel M08 0.625 8
GF1 G10 ASSY galvanised malleable iron M10 0.750 5

Installation Example

Galvanised J / M Steel Grating Clips Fastener Stainless Steel Surface

Step 1 Step 2 Step 3
Lower the GrateFix through the open part of the grating, ensure the bracket is seated over the adjacent bearing bars. Slide the GrateFix towards the supporting steelwork flange as far as it will go to ensure maximum clamping force. Tighten the screw and ensure that the lower casting rotates until one of the steps locates on the bearing bar.

Galvanised J / M Steel Grating Clips Fastener Stainless Steel SurfaceGalvanised J / M Steel Grating Clips Fastener Stainless Steel Surface

Grating Clips are used for fixing down open steel flooring and provide an easy, quick and cost effective method of fixing.

Supplied in mild steel with galvanised finish or stainless steel.

Our technical staff are available to discuss your project or applications with you.
