Heavy Gabion Rock Baskets For Retaining Walls 3.0 - 6.0mm Wire Gauge
Heavy Gabion Rock Baskets For Retaining Walls 3.0 - 6.0mm Wire Gauge
Heavy Gabion Rock Baskets For Retaining Walls 3.0 - 6.0mm Wire Gauge
Heavy Gabion Rock Baskets For Retaining Walls 3.0 - 6.0mm Wire Gauge
Specifications
Model Number :
Gabion box
Certification :
sgs
MOQ :
50 Square Meter
Price :
US $0.4-16.5 / Square Meter
Supply Ability :
300000 Square Meter/Square Meters per Month
Delivery Time :
Shipped in 20 days after payment
Packaging Details :
Flat packed on pallet or as your requirement.
Raw Material: :
Galvanized Iron Wire, Low-Carbon Iron Wire
Type: :
Welded Mesh
Hole Shape :
Square,Hexagonal
Aperture: :
37.5*75mm,50*50mm,75*75mm,50*100mm
Wire Gauge: :
3.0-6.0mm
Surface treatment: :
Galvanized or PVC Coated
Zinc Thickness: :
>=300g/m2
BOXES SIZE: :
0.3x1x1m, 1x1x2m,1x1x0.5m ect.
Description

Heavy galvanized river retaining wall blocks gabion box wire mesh

Gabion mesh is known as by different shape of gabion box,gabion basket, gabion sacks, gabion
mattresses, etc.It is hexagonal wire netting and can be finished by hotdipped galvanized, galvanized
aluminum alloy or PVC coated.

Hexagonal wire mesh is also called chicken wire mesh , rabbit Netting , hexagonal mesh.


1. Material
super quality low carbon iron wire, galvanized wire, PVC coated wire, stainless steel wire, etc.

2. Weaving types
normal twist, reverse twist, double twist.

3. Feature:
Firm structure, Flat surface, Great corrosion resistant, Oxidation resistant, Durable, High intensity.

4. Application:
hexagonal Chicken mesh garden for bird , chicken mesh, protection etc. Poultry or small animals.

Galvanized hex.wire netting in normal twist
(In 30m roll, width of 0.5m-2.0m)
Mesh Wire Gauge
(BWG)
Size mm
3/8″ 10mm 27,26,25,24,23,22,21
1/2″ 13mm 25,24,23,22,21,20
5/8″ 16mm 27,26,25,24,23,22
3/4″ 20mm 25,24,23,22,21,20,19
1″ 25mm 25,24,23,22,21,20,19,18
1-1/4″ 32mm 22,21,20,19,18
1-1/2″ 40mm 22,21,20,19,18,17
2″ 50mm 22,21,20,19,18,17,16,15,14
3″ 75mm 21,20,19,18,17,16,15,14
4″ 100mm 17,16,15,14

Galvanized hex.wire netting in reverse twist
(In 30m roll, width of 0.5m-2.0m)
Mesh Wire Gauge Reinforcement
Size mm BWG Widths (ft) Strand
1″ 25mm 22,21,20,18 2′ 1
1-1/4″ 32mm 22,21,20,18 3′ 2
1-1/2″ 40mm 20,19,18 4′ 3
2″ 50mm 20,19,18 5′ 4
3″ 75mm 20,19,18 6′ 5
Mesh Opening
Wire Diameter
Selvedge Wire
Lacing Wire
60X80mm
2.0-2.8mm
3.0-4.0mm
2.0-2.4mm
80X100mm
2.0-3.0mm
3.0-4.0mm
2.0-2.4mm
100X120
2.0-3.0mm
3.0-4.0mm
2.0-2.4mm
100X150
2.0-3.0mm
3.0-4.0mm
2.0-2.4mm
120X150
2.0-3.0mm
3.0-4.0mm
2.0-2.4mm
Special specifications can be customized according to customer requirements.

Products Show

Heavy Gabion Rock Baskets For Retaining Walls 3.0 - 6.0mm Wire GaugeHeavy Gabion Rock Baskets For Retaining Walls 3.0 - 6.0mm Wire GaugeHeavy Gabion Rock Baskets For Retaining Walls 3.0 - 6.0mm Wire Gauge
FAQ

1.Q: Can you offer free sample?
A:Yes, but usually the customer need to pay the freight
2.Q: Are you a manufacturer?
A: Yes, we have been in providing the professional products in fence field for 10 years.
3.Q: What information should I provide if I want a lowest quotation?
A:The specification of the fence
4.Q:Can I customize the products?
A:yes, as long as provide specifications, drawings, can only do what you want products.
5.Q:what is the quality warranty?
A: Five years’ quality warranty
6.Q: how about the delivery time?
A:Usually within 15- 20days,customized order may need longer time.
7.Q: How about the payment terms?
A:T/T ( with 30% deposit ) , L/C at sight. Western Union
