Steel Strip Hot Dip Galvanizing Production Line HDGL Cold Coil To Coat Zinc
Steel Strip Hot Dip Galvanizing Production Line HDGL Cold Coil To Coat Zinc
Steel Strip Hot Dip Galvanizing Production Line HDGL Cold Coil To Coat Zinc
Steel Strip Hot Dip Galvanizing Production Line HDGL Cold Coil To Coat Zinc
Steel Strip Hot Dip Galvanizing Production Line HDGL Cold Coil To Coat Zinc
Steel Strip Hot Dip Galvanizing Production Line HDGL Cold Coil To Coat Zinc
Steel Strip Hot Dip Galvanizing Production Line HDGL Cold Coil To Coat Zinc
Steel Strip Hot Dip Galvanizing Production Line HDGL Cold Coil To Coat Zinc
Steel Strip Hot Dip Galvanizing Production Line HDGL Cold Coil To Coat Zinc
Steel Strip Hot Dip Galvanizing Production Line HDGL Cold Coil To Coat Zinc
Steel Strip Hot Dip Galvanizing Production Line HDGL Cold Coil To Coat Zinc
Steel Strip Hot Dip Galvanizing Production Line HDGL Cold Coil To Coat Zinc
Specifications
Brand Name :
JJRS
Place of Origin :
China
MOQ :
1
Price :
USD$1,000,000~USD10,000,000
Payment Terms :
T/T, L/C
Supply Ability :
1-10set/year
Delivery Time :
7-10 months
Packaging Details :
Wooden box;
Application :
building material
Material :
Hot rolled coil, cold rolled coil
Width :
650mm-1300mm
Thickness :
0.3mm-2.5mm
Zinc coating :
30-300g/m2
name :
Steel strip continuous process galvanizing line (metal ss)
keyword :
Steel Continuous Galvanizing Line
type :
continuous
process :
hot dip
material :
steel metal ss cs
componet :
entry looper
capacity :
250,000t/year
Description

Hot Dip Galvanizing (HDGL) steel cold coil to coat zinc

We supply continuous Hot dip galvanizing (HDGL) steel cold coil to coat zinc on it.
The continuous hot-dip galvanizing line has an in-line annealing furnace, with an atmosphere comprised of a mixture of nitrogen and hydrogen to avoid oxidation of the steel ,followed by a molten zinc pot to galvanize the steel, The in-line furnace softens the steel through an annealing process, while the molten zinc pot, along with an air wiping mechanism, controls the application and mass of zinc coated on the steel. The product after zinc coating is referred to as galvanized steel, The zinc coating designations based on the zinc coating mass, and is avalable with regular spangle and mini-skin-passed spangle surfaces. While galvanized steel with a regular-spangle surface finds applications in many industries, including ducting, the product is not suitable for applications which require painting. Mini-skin-passed spangle, which has a uniform surface texture, is the most suitable product for painting applications.

We provide two kinds of technologiesof hot dip galvanizing (galvalume) lines: "United States Steel Corp"and independently researched and developed “JJRS-Sendzimir” .

Low-carbon steel wire
in accordance with the standard of hot-dip galvanizing of the corresponding low-carbon steel wire
Product specifications
Φ1.6 ~ 4.0mm
Tensile strength
low carbon 450 N/mm2 ~ 550 N/mm2
Thickness of zinc layer
galvanized 40~80/150~ 300 g/m2
Production speed
D / V40 ~ 60 (maximum 80)
The number of steel wire
12
Steel wire spacing
pre-treatment 35mm; zinc 45mm
The length of the production line tooling
about U-shaped structure 140m
Heating energy
mixed gas or converter gas, electric energy
Power requirements
~ 380V, 50Hz

Steel Strip Hot Dip Galvanizing Production Line HDGL Cold Coil To Coat ZincSteel Strip Hot Dip Galvanizing Production Line HDGL Cold Coil To Coat Zinc

Steel Strip Hot Dip Galvanizing Production Line HDGL Cold Coil To Coat ZincSteel Strip Hot Dip Galvanizing Production Line HDGL Cold Coil To Coat Zinc
