GI Hot Dip Galvanizing Line Equipment 0.15-0.8mm 1250mm 200000TPY
GI Hot Dip Galvanizing Line Equipment 0.15-0.8mm 1250mm 200000TPY
GI Hot Dip Galvanizing Line Equipment 0.15-0.8mm 1250mm 200000TPY
GI Hot Dip Galvanizing Line Equipment 0.15-0.8mm 1250mm 200000TPY
Specifications
Brand Name :
JJRS
MOQ :
1set
Supply Ability :
10-12 set/year
Delivery Time :
7~10 months
Packaging Details :
wooden box; plastic package
Material :
Cold Rolling Coil, Hot Rolling Acid Pickling Coil
Thickness :
0.15~0.8mm
Width :
1250mm
Annual Output :
200,000 ton
Type :
continuous
Coating :
Galvanizing, Painting, Plating, Hot dip galvanizing, zinc coat
After-sales service provided :
Engineers available to service manchinery overseas, field installation, online support
Name :
Continuous Galvanizing Line
Production mode :
double/single work line
Price :
USD$1,000,000~USD10,000,000
Description

New Generation Steel Strip Continuous Annealing

Hot Dip Galvanizing (Aluminizing) Technology --- JJRS-Sendzimir

The special design features of this system deliver the following advantages:
Lowest dewpoints due to excellent furnace sealing concept and up to 100 % hydrogen process atmosphere to avoid surface oxidation, particularly for the highest-quality grades of electrical steel (> 2.5 % Si) at annealing temperatures > 1000 °C
Homogeneous slow cooling over the width of the strip in the cooling zone, for optimum flatness → good punching and laser cutting properties in the electrical steel strip
Material temperatures up to > 1100 °C feasible, especially with highly-efficient power plant grades such as M230-50A (> 3 % Si)
Strip as thin as 0.18 mm can be produced for high-frequency applications
Resource-saving and tailor-made furnace design to minimize wear part, utility and investment costs
The very latest burner/radiant tube technology and rapid heating-up systems for high heating gradients to achieve efficient decarburization and improved texture (crystalline orientation)
Process simulation before heat treatment makes it possible to identify suitable annealing programs to achieve the specified magnetic and mechanical properties
Hydrogen regeneration units, which provide hydrogen savings of up to 50 %, are available

Consolidating the advantages of the traditional technology " Improved Sendzimir" and "United States Steel Corp", and integrating the independently researched and developed regenerative nozzle and waste heat efficient recycling technology, the technology R&D team of Beijing JJRS Technology Development Co.,Ltd, launched a new generation of steel strip continuous annealing hot dip galvanizing process contrl technology based its latest self-designed process control technology by in-depth study and analysis, which is named as " JJRS-Sendzimir".

Technology Patent of " JJRS-Sendzimir"

The launch of " JJRS-Sendzimir" depends on a number of technology patents innovated by ourselves.

  • No-oxidation nozzle burner tehnology
  • Steel strip constant pressure thermal treatment furnace
  • Nozzle arrangement mode (Flame gas orientation heating technology)
  • Hot dip galvanizing technology
  • Regenerative no-oxidation patent technology
  • Low thermal value gas (Blast furnace gas) radiant tube furnace
  • Energy saving radiant tube patent technology
  • Process heat recovery patent technology
  • Energy saving furnace roller
  • Software copyright: galvanized steel strip line control software
1. Inclined channel (section)
2. Filled with shielding gas and protects the heated strip (500°C) from air contact
3. Bottom immersed drum with stellen or ceramic journal bearings
4. Stabilizing roller with journal bearings
5. Correcting roller with journal bearings
6. Noncontact jet device for coating thickness control
7. Electromagnetic strip stabilizer built on air doctor (EM-stabilizer)
8. Bath heating system
9. Removable inducers
10. Gas burners
11. Immersion ceramic heaters
