product name :
DSP Silicon Wafer
brand :
powerway
feature :
No Scratch/Films/Etch Patterns or Residues
Crystalline structure :
Monocrystalline
Thickness :
725 ± 50μm
size :
8"
Description

8" Dummy Grade / Mechanical Grade Silicon Wafer , DSP , Thickness 725 ± 50μm No Scratch Films Etch Patterns Or Residues

PAM-XIAMEN is a manufacturer of CZ and FZ silicon wafer, we now become the worldwide source for high pure silicon wafers,thermal oxide silicon and epi wafers. Silicon wafer is used for integrated circuits , detector / sensor device , MEMS fabrication, opto-electronic components, and solar cells and finally apply to computer, mobile, sensor and other electronics. With rich experiences , PAM-XIAMEN understand your requirements and can provide exactly the silicon products you need with the suitable quality and lowest possible price . PAM-XIAMEN can provide both standard and customized silicon wafers to meet your demands.PAM-XIAMEN offer semiconductor silicon wafer with diameters from 1’’ (25.4 mm) to 12’’ (300 mm). We work either Cz (Czochralski) or FZ (Float Zone) silicon wafers. The polishing process is also made according to SEMI standard( the Semiconductor Equipment and Materials International standards). We also work ultra thin wafer, silicon oxide wafer SiO2 thin film, silicon nitride wafer Si3N4 thin film, thin film deposition and metallization on silicon wafers.

8" Dummy Grade / Mechanical Grade Silicon Wafer, DSP, Thickness 725 ± 50μm, No Scratch/Films/Etch Patterns or Residues

Grade Conduction Type Orientation Diameter(mm) Resistivity(Ω•cm)
Test N&P <100><110>&<111> 50-300 Customer Request
Dummy N&P <100><110>&<111> 50-300 Customer Request
Reclaim N&P <100><110>&<111> 50-300 Customer Request

Parameter Unit Value
Crystalline structure - Monocrystalline
Grade - Dummy
Crystal Orientation - -
Conductance type - -
Dopant - -
Diameter mm 200
Resistivity Ωcm -
Thickness um 725 ± 500µm
TTV um Customer Request
BOW um Customer Request
Warp um Customer Request
(G)STIR um Customer standard
Site Flatness-STIR um Customer standard
Edge Exclusion Zone mm SEMI STD or Customer Request
LPD's - -
Oxygen Concentration ppma -
Carbon Concentration ppma -
RRG - -
Front Surface - Polished
Back Surface - Polished
Edge Surface Condition SEMI STD or Customer Request
Primary Flat Length mm SEMI STD
Primary Flat Orientation(100/111) & Angle(°) SEMI STD
Secondary Flat Length mm SEMI STD
Secondary Flat Orientation(100/111) & Angle(°) SEMI STD
Notch - SEMI STD
no scratch, no films, no etch patterns or residues
Laser mark - SEMI STD or Customer Request
Packaging Packaged in Foam Plastics Case or Black Pizza Case
If specific requirement by customer, will adjust accordingly

What is the application of silicon wafer?

Monocrystalline silicon wafer is mainly used to make semiconductor components, its detail application: it is the raw material of semiconductor silicon device, used for making high power rectifier, high power transistor, diode, switch device, etc. Monocrystalline silicon grown by Czochralski method is mainly used in semiconductor integrated circuit, diode, epitaxial wafer substrate and solar cell. Zone melting single crystal is mainly used in the field of high-voltage high-power controllable rectifier devices, widely used in high-power power transmission and transformation, electric locomotive, rectifier, frequency conversion, electromechanical integration, energy-saving lamp, television and other products. Epitaxial wafer are mainly used in the field of integrated circuits

Are You Looking for an Silicon Wafer?

PAM-XIAMEN is your go-to place for semiconductor wafers, including Silicon wafers, as we have been doing it for almost 30 years! Send us enquiry to learn more about the wafers that we offer and how we can help you with your next project. Our group team can give you technology support. send us email at sales@powerwaywafer.com or powerwaymaterial@gmail.com
