Eco Friendly Movable 2 Point Log Splitter / Diesel Power Wood Splitter
Eco Friendly Movable 2 Point Log Splitter / Diesel Power Wood Splitter
Specifications
Brand Name :
TECHWAY
Model Number :
TW-GS-18T
Certification :
CE
Place of Origin :
China
MOQ :
10pcs
Price :
negotiation
Supply Ability :
10pcs
Delivery Time :
20 working days after received your payment
Packaging Details :
Packed in carton
Product Name :
2 Point Log Splitter
ENGINE :
6.5HP
RAM DIAMETER :
3.0 INCH
RAM TRAVEL :
610MM
HYDRAULIC PUMP :
21MPA
MAX FORCE :
18TON
Description

Eco Friendly Movable 2 Point Log Splitter / Diesel Power Wood Splitter

Features of Carbide Firewood Processor Used Log Splitter :

  1. The design is outstanding: the humanized design of hydraulic splitting machine has the advantages
    of small volume, light weight and compact structure. It ensures that its use is simple and easy to learn, and only needs one person operation.
    2. High accuracy: unlike most traditional chopping methods and equipment, the hydraulic chopper can accurately determine the splitting direction in advance, and can be accurate according to the required split shape and the size required to be taken out.
    3. High safety performance: Hydraulic wood chopper using the hydraulic oil incompressibility and the physical characteristics of mobility, static thrust to achieve static and controllable work. Therefore, there is no need for complex security measures.
    4. Environmental protection type: green wood chopper expert - hydraulic chopper working, will not produce vibration, impact, noise, dust fly dust, and so on, the surrounding environment will not be affected. Even in densely populated areas or indoors, urban construction and close equipment can work without interference.

ITEM

TECHNICAL SPECIFICATION

WEIGHT/CTN/QTY

TW-ES-5T

Horizontal Log Splitter
Motor: 230V/50Hz
Power: 1500W
Max. Splitting Force: 5 Tons
Log Capacity
Wood lengh(Max):520mm
Wood Dia.(Max.): 250mm

43/41kgs
240pcs-20FT
480pcs-40HQ

packing size:
1000*285*460mm

TW-ES-6T

Vertical Log Splitter
Motor:230V~50Hz
Power: 3000W
Max. splitting force:6 Tons
Log capacity
Wood Dia.(Max.):400 mm
Wood lengh(Max):580/770/1060mm

103/98kgs

packing size:
560*460*1100mm

TW-ES-7TA

Vertical Log Splitter
Motor:400V~50Hz
Power: 3000W
Max. splitting force:7 Tons
Log capacity
Wood Dia.(Max.):400 mm
Wood lengh(Max):580/770/1060mm

103/98kgs

packing size:
560*460*1100mm

TW-GS-12T

ENGINE:6.5HP FOUR STROKE
RAM DIAMETER:2.5INCH
RAM TRAVEL:550MM
CONTROL VALVE:60L AUTO-RETURN
HYDRAULIC PUMP:5GAL ONE STAGE
MAX FORCE:12TON
advance: CE certificate
can be used in 3 positions,vertical,horizonal,and also 30 degree
FAST SPEED FOR THE RAM.QUICK WORK

130/115kgs
40PCS/20FT
88pcs/40HQ
plywood packing size
1160*710*480mm

TW-GS-18T

Product name:log splitter
ENGINE:6.5HP
RAM DIAMETER:3.0INCH
RAM TRAVEL:610MM
CONTROL VALVE:AUTO RETURN
HYDRAULIC PUMP:21MPA
MAX FORCE:18TON
TIRE:6.5-8INCH
advance: CE certificate

180/160KGS
44pcs/20FT
94pcs/40HQ
plywood packing size
1790*510*500mm

TW-GS-22T

Product name:log splitter
ENGINE:6.5HP four stroke
PUMP:8GAL TWO STAGE PUMP
RAM DIAMETER:4.0INCH
RAM TRAVEL:610MM
CONTROL VALVE:100L AUTO-RETURN
MAX FORCE:22TON
TIRE:6.5-8INCH
CYCLE TIME:14S
CE certificate

240/220KGS
44pcs/20FT
96pcs/40HQ
plywood packing size
1790*510*500mm

TW-GS-26T

Product name:log splitter
ENGINE:6.5HP four stroke
PUMP:11GAL TWO STAGE PUMP
RAM DIAMETER:4.5INCH
RAM TRAVEL:610MM
CONTROL VALVE:100L AUTO-RETURN
MAX FORCE:26TON
TIRE:6.5-8INCH
CYCLE TIME:14S
CE certificate

240/220KGS
44pcs/20FT
96pcs/40HQ
plywood packing size
1790*510*500mm

TW-GS-34T

PATENT PRODUCT
Product name:log splitter
ENGINE:6.5HP FOUR STROKES
WEDGE HEIGHT:200MM
LOAD CAPACITY :LENGTH:610MM DIAMETERE:750MM
TIRE:6.5-8 CYCLE TIME :3SECONDS
H-BEAM HEIGHT :630MM
OVER HEIGHT:970MM
OVER LENGTH:2150MM
WIDTH:780MM
MAX FORCE:34TON
FLYWHEEL MAX RPM:430
CLUTCH:Yes
ADVANTAGE: CE certificate
FRONT BRAKE WHEEL ,FAST SPEED FOR
NO HYDRAUIC OIL,NO LEAKING

235/215KGS
30PCS/20FT
84PCS/40HQ
plywood packing size
1730*480*850mm

TW-DS-40T

Product name:log splitter
ENGINE :178F DIESEL
RAM SIZE:5.0INCH RAM
RAM TRAVEL:610MM
MAX FORCE:40T
WEDGE:FOUR WAY
CONTROL VALVES:AUTO-RETURN
TYRE:6.5-8 CYCLE TIME:18S
ADVANCE: CE certificate
TAIL LIGHT
ELECTRIC START
LOWER ENGINE POSITION
HYDRAULIC OIL METER
SPECIAL DESIGN OF TAKING OUT DIRTY STUFF FROM THE TANK

1PC/2CTN
40PCS/20FT
82PCS/40HQ

packing size:
machine:plywood
1815*535*510mm
engine: carton
510*410*450mm

310/290KGS

Application

Carbide Firewood Processor Used Log Splitter is widely used in forestry working, such as splitting or dividing round logs, square blocks and wood staff etc.

Performance:

firewood processor is the most economical log splitter for home use . This machine will quickly and efficiently cut and split logs up to 38cm in diameter and 61cm in long. It’s cycle time is 6~8 seconds. Produces is about 5m³/hour.
