Annealed Heat Resistant Stainless Steel Metal Flexible Gas Hose Tube

There are many types of stainless steel specifications. The general specifications are 0.2 to 1.5mm in thickness and DN15 to 4000mm. The connection methods can also be simply distinguished: the stainless steel bellows connection methods are divided into flange connection, welding, thread connection, and quick connector connection. Small diameter metal hoses are generally connected by thread and quick joints, and larger diameters are generally connected by flanges. Connection and welding.

Product Features

1. High-quality imported 304 stainless steel, with nickel content ≥8.0%, over 50 years of service life of the

stainless-steel pipe body.

2. Deeper and denser corrugation, with better flexibility and safety.

3. Integrated pipe fittings and pipes, making the installation easier and faster;

4. Short and hidden tube neck inside the tube, good protected and invulnerable to damage

Highlights of Product —— SAFE USE OF GAS FOR THE WHOLE FAMILY

01/ Protective sleeve,flame-retardant material Outer sleeve adopts insulating and flame-retardant material, which effectively prevents burning, and it is automatically extinguished without fire sources.

02/ SS304 hose, rat bite-proof The high-strength SS304 hose is with high pressure bearing, can also effectively prevent gas leakage caused by rat bites

03/ Thick copper pipe, well connection seal The pipe fittings are made of HPb59-1 copper, electroplated surface, built-in sealing rings (NBR rubber), with excellent sealing performance.

04/ Super flexibility, bend at will The design of corrugated hose secures its very good flexibility, bend at will, convenient installation.

05/ Air grooves The cover sleeve with air grooves can guide the leaking gas to flow to the detective hole at the connecting ends, for purpose of accurate monitoring.

PRODUCT PARAMETERS

Brand: Konch Gas
Product name: Stainless steel corrugated hose for gas
Inner tube: SS304
Outer sleeve: Soft PVC, flame-retardant
Connectors: Copper HPb59-1, SS30408
Sealing ring: NRB (Nitrile Butadiene Rubber)
Nominal pressure: PN≤0.2MPa
Working temperature: -20℃ to 120℃
Application: Pipeline of gas, LPG, natural gas, biogas and connections to gas appliances.

PRODUCT COMPARISON

INSTALLATION STEPS

WORKSHOP AND EQUIPMENT

6 Production lines for stainless steel gas pipes, and10 lines for PVC-U/ PPR water pipes
