Food Industry 10 Ton Steam Boiler High Thermal Efficiency Long Service Life
Food Industry 10 Ton Steam Boiler High Thermal Efficiency Long Service Life
Food Industry 10 Ton Steam Boiler High Thermal Efficiency Long Service Life
Food Industry 10 Ton Steam Boiler High Thermal Efficiency Long Service Life
Food Industry 10 Ton Steam Boiler High Thermal Efficiency Long Service Life
Food Industry 10 Ton Steam Boiler High Thermal Efficiency Long Service Life
Specifications
Brand Name :
WILFORD
Model Number :
WNS Steam Boiler
Certification :
CE
Place of Origin :
China
MOQ :
1 Set
Price :
Negotiation
Payment Terms :
L/C, T/T
Supply Ability :
50 Sets Per Month
Delivery Time :
15-20 Work Days
Packaging Details :
Accessories wooden box packaging
Product name :
10 Tons Gas Fired Steam Boiler For Industrial Production
Rated evaporation :
0.5-4T/h
Rated working pressure :
0.7-1.25Mpa
Fuel :
oil Fired
Style :
Horizontal
Weight :
3.3-13.8T
Description

10 Tons Gas Fired Steam Boiler For The Food Industry

Product introduction

  • Above boilers use international most mature three-pass all wet back structure,safety and reliable.

  • Using waveform furnace increases the stiffness of the furnace and effectively reduces the thermal stress of the furnace.

  • Enhance heat transfer and promote the combustion of fuel in the furnace.

  • During the operation,,the water level fluctuation is small .Big distance between two ends boiler ,big diameter of tubes.

  • All of these ensure good natural circulation .

  • Steam boiler with very small heat loss because of unique furnace and flue gas thermal surface design .

Parameter

Model WNS0.5 WNS1 WNS1.5 WNS2 WNS3 WNS4
Project Unit
Rated evaporation t/h 0.5 1 1.5 2 3 4
Rated working pressure MPa 0.7 1 1 1 1 1.25
Staturated steam temperature ℃ 170 184 184 184 184 193
Fuel consumption Light diesel oil kg/h 35 70 105 140 210 260
Natural gas Nm³/h 40 80 120 160 240 280
LPG Nm³/h 15 30 45 60 90 120
City gas Nm³/h 85 170 250 340 510 680
a Main steam valve diameter DN 40 65 65 80 80 100
b Safety valve diameter DN 40 50 50 40×2 40×2 50×2
c Inlet diamater DN 25 25 40 40 40 50
d Blowoff Valve diameter DN 40 40 40 50 50 50
e Chimney diameter DN 250 300 350 400 450 500
Overall size L mm 3800 4500 4700 4800 5500 6310
L1 mm 3100 3200 3600 3800 4500 5230
W mm 1900 2300 2800 2900 2900 2950
W1 mm 1000 1880 1900 2150 2350 2350
H mm 2100 2680 2950 3250 3880 3120
H1 mm 1800 1980 2070 2250 2450 2530
Weight T 3.3 4.6 5.5 6.3 10.6 13.8

Characteristics

1 . Thermal efficiency up to 98%


2 . Long service life


3 . Applicable fuels include: natural gas, liquefied gas, city gas


4 . Scope of application: central heating, heating

Product Details

Food Industry 10 Ton Steam Boiler High Thermal Efficiency Long Service Life

Application

  • Washing ironing industry: dry washer, dryer and washing machine, dryer, ironing machine, electric iron, and other ancillary equipment.

  • Food machinery industry: tofu machine, steam box, sterilization pot, packing machine, coating equipment, sealing machine, such as supporting the use of equipment.

  • Biological Chemical Industry: fermentation tank, reaction kettle, sandwich pot, mixer, emulsifying machine supporting the use of equipment.

  • Other industries: oil field, car) steam cleaning industry, (hotel, school, dormitory, batch plant) , (Bridges, railways) concrete curing, leisure (salon), sauna bath, heat exchange equipment.

Project case diagram

Food Industry 10 Ton Steam Boiler High Thermal Efficiency Long Service Life

Product tags

steam boiler systems

,

industrial food boiler

,

steam boiler capacity
