Specifications
Brand Name :
Powerplus
Certification :
ISO 9001
Place of Origin :
China
MOQ :
1 SET
Payment Terms :
L/C, T/T
Supply Ability :
10 SETS PER MONTH
Delivery Time :
9-12 Months
Packaging Details :
Plyfilm or plywood suitable for sea shipping
Engine Brand :
MAN
Output rating :
450-990kW
Fuel Type :
Heavy Fuel Oil
Emissions :
Compliant with local regulations
Cooling Method :
Water Cooled
Model :
HFO Power Plant
Frequency :
50Hz-60Hz
Warranty :
12 Months/ 1000 Working Hours
Alternator :
Stamford, Marathon, Leroy Somer, Mecc Alte
Control Panel :
Smartgen, Deepsea, ComAp
Color :
Customized
Description

Quick Installation 1000rpm 1200rpm MAN L16/24 Series Fuel Economy HFO Generator Set

Man HFO Generator Sets Specifications:

Engine-Genset Output (kW) Data of Engine Overall size (mm) Dry Mass (kg)
1000r/min/50Hz 1200r/min/60Hz Type Bore/Stroke
(mm)		 Structure Length Width Height
450-430 500-475 5L16/24 160/240 In Line 4151 1000 2226 9500
540-515 660-625 6L16/24 4516 10500
630-600 770-730 7L16/24 4886 11400
720-685 880-835 8L16/24 5256 12400
810-770 990-940 9L16/24 5531 13100

● The MAN L16/24 diesel engine represents a pinnacle of design in diesel generator sets, offering a power range of 450-990KW and standing as one of the world's premier options. It is fully compliant with future IMO NOx emission standards, promoting environmental conservation.
● Capable of running on HFO/Crude Oil, the MAN L16/24 significantly lowers operating costs across its entire load range.
● The layout of the L16/24 generator set is straightforward and harmonizes seamlessly with MAN B&W propulsion engines, enhancing ease of operation and maintenance. Its pipeless design streamlines components, enhancing reliability.
● Integration of a Lambda controller in the L16/24 diesel engine ensures thorough fuel combustion in cylinders, minimizing engine contamination and wear during load increases.
● With minimal vibration, the MAN L16/24 generator set incorporates effective noise isolation measures for a quieter operation.
