Specifications
Brand Name :
RENO
Model Number :
L1PB20-32-A(C3)
Certification :
ISO14001,OHSAS18001,ISO9001,3C
Place of Origin :
CHINA,QINGDAO
MOQ :
Negotiable
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
10000pcs per month
Delivery Time :
30days after receiving the deposit
Packaging Details :
ach product in plastic bag which comes with the product instructions and foam packaging, then carton packaging outside with another thicker plastic bag.
Way to install :
Wall Mounted
Power out(kw) :
18-28.8kw
Power (KW) :
20-32kw
Shell Material :
Stainless Steel
Gas style :
NG/LPG
Color shows :
white
Product Name :
Wall hung Gas Boiler
Gas pressure(pa) :
2000/2800pa
Dual funtions :
heating and bathing
protection measures :
21 kinds of protection measures
Displaying :
LED Displayer Optional
Heating efficiency(%) :
≥90%
Description

20-32kw Type Wall Hung Gas Hot Water Boiler Dual Function And Use Imported Componets And Assembled In China

GAS WALL HANGING BOILER INSTRUCTIONS

1. Safe and Reliable

With 21 kinds of safe protection•Low failure rate

2. Comfort

Ultra-quiet operation•more comfortable

3. Convenience

Touch control•more precise

4. Environmental protection

Eenrgy saving and environmental protection•Follow the trend

5. After sale

7*24 after-sales service,worry free

TECHNICAL DATA OF GAS WALL HANGING BOILER

MODEL No. L1PB20-32-A(C3)

SPECIFICATIONS

 A20-32-TG1/BH1

RATED INPUT POWER(KW)

 20-32kw

RATED OUTPUT POWER(KW)

 18-28.8kw

HEAT EFFICIENCY(%)

 ≥90%

RATED VOLTAGE FREQUENCY(V/Hz)

 220/230/50

GAS TYPE

 NG/LPG

GAS PRESSURE(Pa)

 2000/2800Pa

TEMP.RANGE OF HEATING WATER(℃)

DHW:30-60 HEATING HOT WATER:30-80

△T=30℃ HOT WATER SUPPLY(KG/MIN)

 8-13

APPLICATIVE WATER PRESSURE(MPA)

 0.02-0.8
DIMENSION(HIGH*WIDE*THICK) 740*410*315
WEIGHT(KG) 30-38kg
DIAMETER OF SMOKE PIPEφ(COAXIAL) φ60/100

PRODECT DISPLAYImported Components Gas Combi Boilers 20kw Wall Hung Lpg Hot Water BoilerImported Components Gas Combi Boilers 20kw Wall Hung Lpg Hot Water BoilerImported Components Gas Combi Boilers 20kw Wall Hung Lpg Hot Water BoilerImported Components Gas Combi Boilers 20kw Wall Hung Lpg Hot Water BoilerImported Components Gas Combi Boilers 20kw Wall Hung Lpg Hot Water Boiler

ABOUT US

Qingdao Hiounce hvac equipment co., Ltd., located in "brand, the beautiful coastal city - qingdao, China, was founded in the 1950s of the qingdao municipal restructuring state-owned enterprises - qingdao boiler factory. it is a company dedicated to research and development, production of high-grade wall hanging furnace, the electric heating furnace, biomass heating boiler, kitchen burning gas, discharge of oil absorption and the module of boiler fuel gas high-tech enterprises.

Qingdao Hiounce hvac equipment co., Ltd.have more than 100 employees.Company headquarters has total handling, personnel department, finance department, marketing department, the ministry of commerce, office (provincial), purchasing, and import and export department, technology department, engineering department, after-sales service department, and other functions of the eleven departments, through the perfect sales and service network, security, stability, energy saving, environmental protection products supply users.Imported Components Gas Combi Boilers 20kw Wall Hung Lpg Hot Water Boiler
