4-20mA Output Water Pressure Transmitter for Performance and Customized OEM Support
4-20mA Output Water Pressure Transmitter for Performance and Customized OEM Support
4-20mA Output Water Pressure Transmitter for Performance and Customized OEM Support
4-20mA Output Water Pressure Transmitter for Performance and Customized OEM Support
4-20mA Output Water Pressure Transmitter for Performance and Customized OEM Support
4-20mA Output Water Pressure Transmitter for Performance and Customized OEM Support
4-20mA Output Water Pressure Transmitter for Performance and Customized OEM Support
4-20mA Output Water Pressure Transmitter for Performance and Customized OEM Support
4-20mA Output Water Pressure Transmitter for Performance and Customized OEM Support
4-20mA Output Water Pressure Transmitter for Performance and Customized OEM Support
4-20mA Output Water Pressure Transmitter for Performance and Customized OEM Support
4-20mA Output Water Pressure Transmitter for Performance and Customized OEM Support
Specifications
Warranty :
12 month
Customized support :
OEM, ODM
Place of Origin :
Beijing, China
Brand Name :
IVANPER
Model Number :
AF501
Output :
4-20mA
Packaging Details :
carton
Supply Ability :
1000 Unit/Units per Week
MOQ :
10 units
Price :
$30.00 - $40.00/units
Description
AIR PRESSURE SENSOR water pressure transmitter
Product Description
4-20mA Output Water Pressure Transmitter for Performance and Customized OEM Support
4-20mA Output Water Pressure Transmitter for Performance and Customized OEM Support
Specification
Measurement Range
-0.1．．．0~0.01．．．~100MPa
Proof pressure
≤1.5X rated pressure or 110MPa which ever is less
Pressure type
Gauge, absolute ,sealed gauge
Accuracy
±0.25%（typical） ±0.5%（Max.）
Long term stability
±0.1%F.S/year（typical） ±0.2%F.S/year（Max.）
Temperature Error- Zero
±0.03%F.S/℃（≤100KPa） ±0.02%F.S/℃（＞100KPa）
Temperature Error -Span
±0.03%F.S/℃（≤100KPa） ±0.02%F.S/℃（＞100KPa）
Operating Temperature Range
-20℃~80℃
Storage Temperature Range
-40℃~120℃
Power supply
15～30VDC
Output signal
4～20mA 0～10/20mA 0/1～5/10VDC
Pressure port
M20×1.5,G1/2 or customize
Housing material
1Cr18Ni9Ti stainless steel
Diaphragm material
316L
O-ring
Fluororubber
Cable
polyethylene
Insulation resistance
100MΩ,100VDC
Protection
IP65
Packing & Delivery
4-20mA Output Water Pressure Transmitter for Performance and Customized OEM Support
4-20mA Output Water Pressure Transmitter for Performance and Customized OEM Support
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
Company Profie
4-20mA Output Water Pressure Transmitter for Performance and Customized OEM Support
4-20mA Output Water Pressure Transmitter for Performance and Customized OEM Support
4-20mA Output Water Pressure Transmitter for Performance and Customized OEM Support
Semi-Automatic PET Bottle Blowing Machine Bottle Making Machine Bottle Moulding Machine
PET Bottle Making Machine is suitable for producing PET plastic containers and bottles in all shapes.
Recommend Products
Packing & Delivery
4-20mA Output Water Pressure Transmitter for Performance and Customized OEM Support
4-20mA Output Water Pressure Transmitter for Performance and Customized OEM Support
Company Profile

Beijing Ifpen Instrument EnterpriseWas founded in 2011, adjacent to the beautiful political and cultural center, located in Daxing Industrial Development Zone, Beijing.The company has a professional, innovative technica team and standardized production team. Over the years, we have been committed to the research and development of industrial instrument production, focusing on the research and development of the field of"wind speed and air volume", and achieving zero breakthrough of turbulence jump. Since its establishment, the company insists on"innovation, quality, integrity" to serve the new and old customers. Ivan products not only occupy a high proportion of market share in China, as a national brand, go abroad, exported to the world.
4-20mA Output Water Pressure Transmitter for Performance and Customized OEM Support
Exhibition
4-20mA Output Water Pressure Transmitter for Performance and Customized OEM Support
Certifications
4-20mA Output Water Pressure Transmitter for Performance and Customized OEM Support
4-20mA Output Water Pressure Transmitter for Performance and Customized OEM Support
FAQ
FAQ for better and easy cooperation:
1.Why choose IVAN?
We are the leading manufactuer, OEM & ODM service areoffered
2.How about the sample of IVAN product?
We could send you the samples but the freight and the sample are charged.
4.How about IVAN payment term?
TT &L/C &Westem Union(40% deposit, the balance before shipment)
5.How about BIOBASE delivery time?
Within 7-15 workdays after receving deposit
6.How about IVAN validity of quotation?
Usualy 30 days as the shipping freight and exchange rate can be fluctuant.
7.What is the shipping port?
FOB to Qingdao Port, China(also can ship according to customers' request)
8.How about the package?
Bubble film+ Coton +Standard export wooden case.
9.How to inspect the goods?
Products i be checked by our QC staffist then our proejct manager. Cient can come and check bythemselves or third party check is available.
Any quesion or help pease felfre t contact with any time!
