Cylinder 3.3uF High Frequency Capacitor ALCON FP-11-500
Cylinder 3.3uF High Frequency Capacitor ALCON FP-11-500
Specifications
Brand Name :
GDHY
Model Number :
C41751335KBE1501-01
Certification :
SGS,ISO
Place of Origin :
CHINA
MOQ :
20 PCS
Price :
USD 86 / PCS
Payment Terms :
T/T, Western Union, MoneyGram
Supply Ability :
1000 PCS/MONTH
Delivery Time :
14 DAYS
Packaging Details :
ΦD*H*Φd= 88*71.5*60MM FOAM BOX WITH ANTI-CORRSION PROTECTION.
MATERIAL :
IMPORTED COPPER FOIL
CHARACTERISTICS :
WATER COOLED, CONDUCTION COOLED, EXCELLENT HEAT DISSPATION.
LEAD ELECTRODE :
COPPER SHEET
SHAPE :
CYLINDER
PRINTING METHOD :
LASER MARKING
QUALITY CERTIFICATE :
ISO 9001
APPLICATION FIELD :
NEW ENERGY FIELDS; TRANSPORTATION FACILITIES; HIGH POWER INDUSTRIAL FACILITIES:
QUALITY CONTROL :
IQC, SPC, INSPECTION, WAREHOUSING
COMPANY HISTORY :
SINCE 1998
PRODUCTION MODE :
AUTOMATIC
EXPERIENCE :
OVER 22 YEARS
ADVANTAGE :
KEEP LOW DF AND LONG LIFE EXPECTANCY
CAPACITANCE VALUE :
3.3μF
CERTIFICATION :
ISO,SGS
BRAND NAME :
GDHY
TYPE :
FILM CAPACITOR
OPERATION TEMPERATURE :
-40℃～85℃
RATED POWER :
500KVAR
RATED VOLTAGE :
750VAC
MODEL NUMBER :
C41751335KBE1501-01
CAPACITY TOLERANCE :
±10%
LIFE EXPECTANCY :
100000h at UN and 70℃,30000h at Urms
SIZE(D*H) :
88*71.5MM
FREQUENCY :
43-62KHZ
CURRENT :
800A
ESR :
1.0mΩ
Description

C41-BE1 3.3UF/750V/500KVAR ALCON FP-11-500/CELEM C500T RESONANT CAPACITOR CONDUCTION COOLED

Technical Parameter

Reference Standards GB/T 3984-2004 IEC 60110.1
Operating Temperature Range -40℃～85℃
Capacity Range 1.2-21μF
Rated Power 500kVar
Rated Voltage 400-1100VAC
Capacity Tolerance ±10%
Test Voltage between Terminals 1.5UNAC 10s
2~3.5UNDC 10s at 25℃±5℃
Dissipation Factor tgδ≤5×10-4 at 25℃±5℃,1kHz
Insulation Resistance R•C≥3000s,at 100VDC,25℃±5℃,60s
Life Expectancy 100000h at UN and 70℃,30000h at Urms

Specification download:C41-BE1.pdf

Application

Induction heating, heat treatment, plasma applications, resonant circuits, medical imaging, wireless power transfer, EV (electric vehicle) charging, IPT, high frequency inverters,etc.

Features

● Conduction water-cooled

● Polypropylene dielectric

● Low dissipation factor(tgδ), low ESL, low ESR

● High voltage, high frequency and high dV/dt,

● Can bear large current, excellent heat dissipation

Product picture

Cylinder 3.3uF High Frequency Capacitor ALCON FP-11-500

Product shape

Cylinder 3.3uF High Frequency Capacitor ALCON FP-11-500

Production Line

Cylinder 3.3uF High Frequency Capacitor ALCON FP-11-500

Workshop & Equipment

Cylinder 3.3uF High Frequency Capacitor ALCON FP-11-500

Exhibition

Cylinder 3.3uF High Frequency Capacitor ALCON FP-11-500

Certification

Cylinder 3.3uF High Frequency Capacitor ALCON FP-11-500

Packing method

Cylinder 3.3uF High Frequency Capacitor ALCON FP-11-500
