1μF 400VDC CBB Polypropylene Film Capacitor Pitch 20+-0.5mm
1μF 400VDC CBB Polypropylene Film Capacitor Pitch 20+-0.5mm
1μF 400VDC CBB Polypropylene Film Capacitor Pitch 20+-0.5mm
1μF 400VDC CBB Polypropylene Film Capacitor Pitch 20+-0.5mm
Specifications
Brand Name :
GDHY
Model Number :
CBB22-105J400V-20RUN-3U
Certification :
SGS,ISO
Place of Origin :
GUANGZHOU, CHINA
MOQ :
10KPCS
Price :
0.5 USD/ PCS
Payment Terms :
Western Union, MoneyGram, T/T
Supply Ability :
1000 KPCS
Delivery Time :
about 14 DAYS
Packaging Details :
plastic bag and carton
Place Of Origin :
Guangzhou, China
Supplier Type :
Original Manufacturer
Classification :
Polypropylene Film Capacitor
Model number :
B1050400-D-20-3U
material :
Metallized polypropylene film
Operating Temperature Range :
-40℃～85℃
Capacitance :
1UF
Capacity Tolerance :
±5%
Rated DC Voltage :
400VDC
Pitch :
20±0.5mm
height :
7.5mm
width :
23mm
thickness :
12.5mm
Description

Original manufacturer, 1μF 400VDC, Polypropylene Film Capacitor,Pitch 20+-0.5mm

1μF 400VDC CBB Polypropylene Film Capacitor Pitch 20+-0.5mm

Technical Parameter

Reference Standards GB/T 10190(IEC 60384-16)
Climate Category 40/085/21
Operating Temperature Range -40°℃~85°℃
Capacitance 1μF
Rated Voltage 400VDC
Capacity Tolerance ±5%
Withstand voltage Vtet:1.6UN 5S (at20±5℃)
Insulation Resistance

C≤0.33uF R≥100000MQ(at20°℃ 100VDC 1Min)

C>0.33 uF RCN≥30000s (at20℃ 100VDC 1Min)

Specification download: CBB22.pdf

Application

Widely used in High Frequency, DC, AC, Pulse Circuits. S-correction circuits of the display device

Features

● Metallized polypropylene film dielectric

● Non-inductive winding structure

● Flame retardant epoxy resin powder encapsulation

● Resistance to high voltage, small tg6,low temperature rise

Product picture

1μF 400VDC CBB Polypropylene Film Capacitor Pitch 20+-0.5mm1μF 400VDC CBB Polypropylene Film Capacitor Pitch 20+-0.5mm

Product shape

1μF 400VDC CBB Polypropylene Film Capacitor Pitch 20+-0.5mm

Production

1μF 400VDC CBB Polypropylene Film Capacitor Pitch 20+-0.5mm

Workshop& Equipment

1μF 400VDC CBB Polypropylene Film Capacitor Pitch 20+-0.5mm

Packing method

1μF 400VDC CBB Polypropylene Film Capacitor Pitch 20+-0.5mm

Certificate

1μF 400VDC CBB Polypropylene Film Capacitor Pitch 20+-0.5mm

Exhibition

1μF 400VDC CBB Polypropylene Film Capacitor Pitch 20+-0.5mm
