CBB22 1.3μF 400VDC Polypropylene Film Capacitor Pitch 20±0.5mm
CBB22 1.3μF 400VDC Polypropylene Film Capacitor Pitch 20±0.5mm
CBB22 1.3μF 400VDC Polypropylene Film Capacitor Pitch 20±0.5mm
CBB22 1.3μF 400VDC Polypropylene Film Capacitor Pitch 20±0.5mm
Specifications
Brand Name :
GDHY
Model Number :
CBB22-135J400V-20RN-1R
Certification :
SGS,ISO
Place of Origin :
GUANGZHOU, CHINA
MOQ :
10KPCS
Price :
0.5 USD/ PCS
Payment Terms :
Western Union, MoneyGram, T/T
Supply Ability :
1000 KPCS
Delivery Time :
about 14 DAYS
Packaging Details :
plastic bag and carton
Place Of Origin :
Guangzhou, China
Supplier Type :
Original Manufacturer
Classification :
Polypropylene Film Capacitor
Model number :
B1350400-D-20-1R
material :
Metallized polypropylene film
Operating Temperature Range :
-40℃～85℃
Capacitance :
1.3μF
Capacity Tolerance :
±5%
Rated DC Voltage :
400VDC
Pitch :
20±0.5mm
height :
10.5mm
width :
23mm
thickness :
17mm
Description

CBB22 1.3μF 400VDC, Polypropylene Film Capacitor, Pitch 20±0.5mm

CBB22 1.3μF 400VDC Polypropylene Film Capacitor Pitch 20±0.5mm

Technical Parameter

Reference Standards GB/T 10190(IEC 60384-16)
Climate Category 40/085/21
Operating Temperature Range -40°℃~85°℃
Capacitance 1.3μF
Rated Voltage 400VDC
Capacity Tolerance ±5%
Withstand voltage Vtet:1.6UN 5S (at20±5℃)
Insulation Resistance

C≤0.33uF R≥100000MQ(at20°℃ 100VDC 1Min)

C>0.33 uF RCN≥30000s (at20℃ 100VDC 1Min)

Specification download: CBB22.pdf

Application

Widely used in High Frequency, DC, AC, Pulse Circuits. S-correction circuits of the display device

Features

● Metallized polypropylene film dielectric

● Non-inductive winding structure

● Flame retardant epoxy resin powder encapsulation

● Resistance to high voltage, small tg6,low temperature rise

Product picture

CBB22 1.3μF 400VDC Polypropylene Film Capacitor Pitch 20±0.5mmCBB22 1.3μF 400VDC Polypropylene Film Capacitor Pitch 20±0.5mm

Product shape

CBB22 1.3μF 400VDC Polypropylene Film Capacitor Pitch 20±0.5mm

Production

CBB22 1.3μF 400VDC Polypropylene Film Capacitor Pitch 20±0.5mm

Workshop& Equipment

CBB22 1.3μF 400VDC Polypropylene Film Capacitor Pitch 20±0.5mm

Packing method

CBB22 1.3μF 400VDC Polypropylene Film Capacitor Pitch 20±0.5mm

Certificate

CBB22 1.3μF 400VDC Polypropylene Film Capacitor Pitch 20±0.5mm

Exhibition

CBB22 1.3μF 400VDC Polypropylene Film Capacitor Pitch 20±0.5mm
