ALCON FP-38-300-SM Conduction Cooled Capacitor RoHs Resonant Condensador
ALCON FP-38-300-SM Conduction Cooled Capacitor RoHs Resonant Condensador
ALCON FP-38-300-SM Conduction Cooled Capacitor RoHs Resonant Condensador
ALCON FP-38-300-SM Conduction Cooled Capacitor RoHs Resonant Condensador
Specifications
Brand Name :
GDHY
Model Number :
C411664KTC2151-01
Certification :
SGS,ISO
Place of Origin :
GUANGZHOU, CHINA
MOQ :
20 PCS
Price :
PLEASE CONTACT US FOR DETAILS
Payment Terms :
T/T, Western Union, MoneyGram
Supply Ability :
1000 PCS /MONTH
Delivery Time :
14 DAYS
Packaging Details :
CARTON WITH FOAM BOX AND ANTI-CORRSION PROTECTION
BRAND NAME :
GDHY
EXPERIENCE :
OVER 22 YEARS
PRODUCT TYPE :
WATER COOLED RESONANT CAPACITOR
CAPACITANCE VALUE :
0.66μF
RATED POWER :
150KVAR
RATED VOLTAGE :
600V
CAPACITY TOLERANCE :
±10%
HIGHLIGHTS :
SELF-HEALING
Description

ALCON FP-38-300-SM Conduction Cooled Capacitor RoHs Resonant CondensadorALCON FP-38-300-SM CONDUCTION COOLED CAPACITOR ROHS COMPLIANT RESONANT CONDESADOR

Technical Parameter

Reference Standards GB/T 3984-2004 IEC 60110.1
Operating Temperature Range -40℃～+85℃
Rated Capacitance 0.66μF
Rated Power 150kVar
Rated Voltage 600VAC
Capacity Tolerance ±10%
Test Voltage between Terminals 1.5UNAC 10s
2~3.5UNDC 10s at 25℃±5℃
Dissipation Factor tgδ≤5×10-4 at 25℃±5℃,1kHz
Insulation Resistance R•C≥3000s,at 100VDC,25℃±5℃,60s
Life Expectancy 100000h at UN and 70℃,30000h at Urms

Specification download: C41-TC2.pdf

Application

● This series product is suitable for Induction Heating, Electric Cars, Medical Imaging, EV Wireless Chargers, Resonant Circuits.

● It is also widely used in high power and high frequency resonant devices.

Feature

● Conduction water-cooled

● Polypropylene dielectric

● Self-healing

● Maximum operating coretemperature up to 85℃

● Capacitance tolerance ±10%

● Low dissipation factor(tgδ), low ESL, low ESR

● High voltage, high frequency and high dV/dt,

● Can bear large current, excellent heat dissipation

Product picture

ALCON FP-38-300-SM Conduction Cooled Capacitor RoHs Resonant CondensadorALCON FP-38-300-SM Conduction Cooled Capacitor RoHs Resonant Condensador

Product Shape

ALCON FP-38-300-SM Conduction Cooled Capacitor RoHs Resonant Condensador

Workshop&Equipment

ALCON FP-38-300-SM Conduction Cooled Capacitor RoHs Resonant Condensador

Prodcution

ALCON FP-38-300-SM Conduction Cooled Capacitor RoHs Resonant Condensador

Packing

ALCON FP-38-300-SM Conduction Cooled Capacitor RoHs Resonant Condensador

Exhibition

ALCON FP-38-300-SM Conduction Cooled Capacitor RoHs Resonant Condensador

Certification

ALCON FP-38-300-SM Conduction Cooled Capacitor RoHs Resonant Condensador

Comparison

ALCON FP-38-300-SM Conduction Cooled Capacitor RoHs Resonant Condensador
