0.1UF 2000V VISHAY MKP1845 Axial Audio Film Capacitor HiFi MKP 104 2KV
0.1UF 2000V VISHAY MKP1845 Axial Audio Film Capacitor HiFi MKP 104 2KV
0.1UF 2000V VISHAY MKP1845 Axial Audio Film Capacitor HiFi MKP 104 2KV
0.1UF 2000V VISHAY MKP1845 Axial Audio Film Capacitor HiFi MKP 104 2KV
Specifications
Brand Name :
GDHY
Model Number :
C36203103JX12-01
Certification :
SGS,ISO
Place of Origin :
GUANGZHOU, CHINA
MOQ :
10KPCS
Price :
PLEASE CONTACT US FOR DETAILS
Payment Terms :
Western Union, T/T, MoneyGram
Supply Ability :
1KKPCS/MONTH
Delivery Time :
14 DAYS
Packaging Details :
CARTON WITH FOAM BOX AND ANIT-CORROSION PROTECT.
BRAND :
GDHY
SUPPLIER TYPE :
ORIGINAL MANUFACTURER
MODEL NUMBER :
C36203103JX12-01
CAPACITANCE :
0.1UF/104
RATED VOLTAGE :
2000VDC
COLOR :
WHITE
PRINTING :
LASER MARKING
EXPERIENCE :
OVER 22 YEARS
Description

0.1UF 2000V VISHAY MKP1845 Axial Audio Film Capacitor HiFi MKP 104 2KV0.1UF/2000V 104 2KV VISHAY MKP1845 AXIAL AUDIO FILM CAPACITOR HIFI

Technical Parameter

Reference Standards GB/T 10190(IEC 60384-16)
Climate Category 40/085/21
Operating Temperature Range -40℃～85℃ Tmax 105℃
Capacity Range 0.1μF
Rated Voltage 2000VDC
Capacity Tolerance ±5%(J)；±10%(K)
Withstand voltage 1.6UR (5S)
Dissipation Factor tgδ≤0.0010 (20℃, 1KHz)
Insulation Resistance C≤0.33μF R≥100000MΩ(at 20℃ 100VDC 1Min)
C>0.33 μF RCN≥30000S (at 20℃ 100VDC 1Min)

Application

● High pulse operation and high peak current circuits.

Feature

● Metallized polypropylene film dielectric with non-inductively wound

● Myla tape with flame retardant epoxy resin at both ends

● Axial tin copper wire leads

● Resistance to high voltage, small tgδ, low temperature rise

● Customizable design

Product Picture

0.1UF 2000V VISHAY MKP1845 Axial Audio Film Capacitor HiFi MKP 104 2KV0.1UF 2000V VISHAY MKP1845 Axial Audio Film Capacitor HiFi MKP 104 2KV

Product Shape

0.1UF 2000V VISHAY MKP1845 Axial Audio Film Capacitor HiFi MKP 104 2KV

Production

0.1UF 2000V VISHAY MKP1845 Axial Audio Film Capacitor HiFi MKP 104 2KV

Workshop&Equipment

0.1UF 2000V VISHAY MKP1845 Axial Audio Film Capacitor HiFi MKP 104 2KV

Packing method

0.1UF 2000V VISHAY MKP1845 Axial Audio Film Capacitor HiFi MKP 104 2KV0.1UF 2000V VISHAY MKP1845 Axial Audio Film Capacitor HiFi MKP 104 2KV

Certificate

0.1UF 2000V VISHAY MKP1845 Axial Audio Film Capacitor HiFi MKP 104 2KV

Exhibition

0.1UF 2000V VISHAY MKP1845 Axial Audio Film Capacitor HiFi MKP 104 2KV
